Getting started

A
B
A
D
UCOM Twintalker 4710 DCP
9.1
1.
2.
C
9.2
1.
2.
3.
4.
UCOM Twintalker 4710 DCP
Installing/Removing the Belt
Clip
To install the belt clip, align the pin with
the hole in the backside. Gently push
until it clicks into position.
To remove the belt clip from the unit,
push the belt clip (A), while pulling the
clip away from the unit (B).

Battery Installation

Remove the belt clip (See chapter
9.1.2).
Pull the battery cover tab (C) and gently
remove the battery cover.
Install the rechargeable battery pack
following the polarity as shown. The
metal contacts (D) should face
outwards from the radio to connect on
the battery door. Or install 3 'AAA'
alkaline or rechargeable batteries
following the polarity as shown.
Re-install the Battery Cover and Belt
Clip (See chapter 9.1.1).
7
