4. Technical data

Voltage:
Power consumption:
Working width:
Number of blades
Scarifying depth: Infinitely adjustable up to 10 mm
L sound pressure level:
pA
L sound power level:
WA
Vibration on the shaft a
hv

5. Before starting the equipment

The scarifier is delivered unassembled. The grass
basket and the complete push bar must be
assembled and mounted before using the scarifier.
Follow the operating instructions step-by-step and
use the pictures provided as a visual guide to easily
assemble the machine.
Mounting the lower push bar (see Figs. 3 and 4)
Insert the U-shaped lower push bar into the
holes in the housing (Fig. 3).
Now you can fasten the lower push bar using the
screws supplied (Fig. 4/Item 2c).
Mounting the upper push bar (see Figs. 5 and 6)
Position the upper push bar (Fig. 5/Item 2b) such
that its holes line up with the holes of the lower
bar.
Insert the screw (Fig. 5/Item 2f) with washer (Fig.
5/Item 2e) through the tubes from the outside.
Screw the handlebars together using a star grip
(Fig. 5/Item 5).
Attach the handlebar opposite.
Using the cable clips supplied (Fig. 6/Item 2d),
attach the power cable on the inside of the tubes
of the push bar, so that it is possible to open and
shut the ejector flap (Fig. 1/Item 7).
Important!
Please ensure that the ejector flap can be opened
and closed easily!
Then fit the cable stress-relief clip (Fig. 7/Item 4)
as shown in Figure 7.
14
18.09.2008 10:56 Uhr Seite 14
Mounting the height adjustment
(see Figs. 8 and 9)
Screw the central rod assembly together with the
230 V ~ 50 Hz
pre-mounted upper rod assembly as in Fig. 8.
Important – left-handed thread!
1600 W
Then screw together with the lower rod assembly
39 cm
using the screw (Figure 9/Item 8b).
16 pieces
Assembling the grass basket (see Figs. 10-12)
Fit the grass basket parts as shown in Fig. 10.
85 dB(A)
To fasten the grass basket, pull the rubber clips
over the small frame (Fig. 11).
98 dB(A)
To hang the grass basket on the scarifier you
2.5 m/s 2
must lift the ejector flap (Fig. 1/Item 7) with one
hand and with the other hand take hold of the
grass bag by the handle and hook it onto the
scarifier from above (Fig. 12).
Important! Before you ever hook the grass
basket to the scarifier you must ensure that the
motor is switched off and the cutting unit is not
rotating.
Adjusting the scarifier depth (see Fig. 13)
The scarifier depth is set using the handle (Fig.
13/Item 8) on the rod assembly for the height
adjustment.
Push the engage handle (Fig. 13/Item 6) forward
and set the desired depth (+/-).
To test the working depth, push the operating
lever back and start the machine up. Gently push
the scarifier forward and slowly pull the operating
lever forward. Repeat this process as many
times as required until the desired working depth
is achieved.
Electrical connection
The equipment can be connected to any normal
socket with 230V AC. It is only acceptable to connect
it to a shockproof socket with a 16A circuit breaker.
Furthermore, a residual-current-operated protective
device with max. 30 mA should be connected
upstream.
Power cable
Please only use power cables that are not damaged.
The total length of the power cable should not
exceed 50 meters; going beyond this distance will
reduce the power output of the electric motor. The
power cable must have a cross-section of 3 x 1.5
mm2. The insulating sheath of scarifier power cables
is frequently damaged.
Some of the causes for this are:
Cracking from running over the cable
Pinching when the power cable is dragging
under doors and pulled through windows
Cracking due to old age of the insulation
