Advanced On-Screen Display
OSD Lock Out This control completely locks out access to all OSD control functions. When attempting to activate OSD
controls while in the Lock Out mode, a screen will appear indicating the OSD controls are locked out.
There are three types of OSD LOCK OUT:
MODE
OSD LOCK OUT
with no control
OSD LOCK OUT
with BRIGHTNESS
CUSTOM LOCK OUT
OSD LOCK OUT with no control: To activate the OSD Lock Out function, press SELECT, then ">" key
and hold down simultaneously. To deactivate the OSD Lock Out, press SELECT, then ">" key and hold
down simultaneously while in the OSD menu. No controls can be adjusted while in the lock out mode.
OSD LOCK OUT with BRIGHTNESS control: To activate the OSD Lock Out function, press SELECT,
then "–" and "<" key and hold down simultaneously. To deactivate the OSD Lock Out, press SELECT,
then "–" and "<" key and hold down simultaneously while in the OSD menu. BRIGHTNESS can be
adjusted while in the lock out mode.
CUSTOM: Press RESET and EXIT to enter the CUSTOM Menu. Select ENABLE or DISABLE for
BRIGHTNESS or WARNING (RESOLUTION NOTIFIER/OSD LOCK OUT).
OSD Rotation To switch OSD between Landscape and Portrait modes. Press "+" or "–" to select.
Resolution Notifier The optimal resolution is 1536 x 2048. If ON is selected, a message will appear on the screen after 30
seconds, notifying you that the resolution is not set to 1536 x 2048. Press "+" or "–" to select.
HOT KEY You can adjust the brightness directly. When this function is set to ON, you can adjust the brightness with <,
>, +, or –, while the OSD menu is off. The standard OSD can be accessed with the EXIT button.
LED Brightness Controls the brightness of the LED on the display, "OFF", "MID" and "MAX".
Factory Preset Selecting Factory Preset allows you to reset all OSD control settings (BRIGHTNESS, H.Position, V.Position,
Gamma Selection, Gamma Offset, WHITE POINT SELECTION, SHARPNESS, EXPANSION MODE, OSD
LEFT/RIGHT, OSD DOWN/UP, OSD TURN OFF, SELF CALIBRATION, DISPLAY MODE) back to the factory
settings. Individual settings can be reset by highlighting the control to be reset and pressing the RESET button.
This tag is not adjustable.
Tag8
Tag9
Display Mode Provides information about the current display resolution and technical data, including the preset timing
currently being used and the horizontal and vertical frequencies. Increases or decreases the current
resolution. Press "SELECT" to move the adjustment mode, and press "+" or "–" to adjust horizontal and
vertical resolution.
Monitor Info. Indicates the model and serial numbers of your display.
01_MD21GS3MPINSTALL_EN.P65
Key strokes to enter
SELECT, >
SELECT, – , <
7 step process to Activate:
1. Press RESET and EXIT to enter Advanced OSD
2. Press < to reach Tag 7
3. Highlight the OSD LOCK OUT function
4. Press RESET and EXIT
5. ENABLE or DISABLE: BRIGHTNESS, WARNING
6. Press SELECT to enter the OSD LOCK OUT mode
7. Press EXIT to exit the OSD
To Deactivate:
1. Without OSD menu, press RESET and EXIT to bring
up the LOCK OUT warning
2. Press SELECT, SELECT, <, >, <, >, EXIT
9
–continued
BRIGHTNESS
No
Yes
Selectable
English.9
08/08/2005, 12:00
LOCK OUT Warning
Yes
Yes
Selectable
