sportplus SP-HT-9600-iE Bedienungsanleitung Seite 45

6. ASSEMBLY INSTRUCTIONS
STEP 5
9
1. The left (9) and right (10) pedals are marked with the letters "L" and "R" respectively. The
wordings left or right refer to the side located left or right from you when sitting on the
saddle. Attach the straps to the pedals.
2. Mount the left and right pedals (9/10) to the left and right pedal crank (48 /49). Attach the
pedals by turning the right pedal clockwise and the left pedal anti-clockwise.
3. Connect the adapter (74) to the adapter socket (B) on the back of the main frame (see
detailed illustration).
4. Connect the adapter (74) to a suitable mains outlet.
5. The device is then ready for use.
48
45
10
B
1
