Technical data

Determined on the basis of EN 14511 or Truma test conditions
Power supply
230 V – 240 V , 50 Hz
Power consumption
Cooling: 4.2 A
Heating: 3.7 A
Start-up current
28 A (150 ms)
Cooling power
2.4 kW
Heating power
1.7 kW (heat pump)
Air volume flow
max. 400 m³/h
Usage limits
+4 °C to 40 °C
Maximum angle during operation
8 %
Weight
33 kg plus installation materials
Dimensions (W x H x D)
External: 660 x 248 x 1008 mm
Internal: 523 x 46 x 670 mm
Refrigerant
R 407C / 0.67 kg
Contains fluorinated greenhouse gases covered by the
Kyoto Protocol. Hermetically sealed.
Global Warming Potential (GWP)
1774
CO2 equivalent
1188.6 kg
Subject to technical changes.

Installation dimensions (in mm)

1008
Figure 8
195
(215)
530
Figure 9
20
670
400
(380)

Clearance around the air conditioning system

The clearance around the external unit must be 20 mm at
the front and 100 mm at the side. At least 30 mm of clearance
must be left at the rear. Truma recommends clearance of
200 mm so that the exhaust air can blow out freely.
Figure 10
The clearance around the air distributor must allow the air to
blow out without obstructions. The side clearance must be at
least 40 mm. The pivoting range of flaps and doors must be
taken into consideration.
Figure 11

Air inlets / outlets

Figure 12
