D. Sensor Unit Function keys ***
Your Meteoclock works with 2 AA batteries for the
main unit and 2 AAA for the remote sensor (all not
included).
Battery installation
1. Remote Sensor: Use a screwdriver to open the
battery door located at the back of the remote
sensor unit. Insert 2 AAA batteries according to
the polarity. Close back the battery compartment
and tighten the screw.
2. Main Unit: Use your finger to lift the battery door
located at the back of the main unit. Insert 2 AA
batteries according to the polarity. Close back the
battery compartment.
LOW BATTERY INDICATION: If the batteries of
the remote sensor are low, the following indicator
will be displayed on the main unit, next to the
outdoor temperature display [A10]. Please replace
the remote sensor's batteries. The indicator will also
be displayed on the remote sensor's screen [C4].
When the main unit's LCD display becomes dim, it
indicates that the batteries are low and need to be
changed.
Copyright © Lexibook 2008
Please make sure the main unit has NOT been turned on.
SETTING THE REMOTE SENSOR
1. Unscrew the battery cover located at the back of the sensor unit and insert 2xAAA batteries to
begin the settings.
2. CH 123 will be displayed [C1]. Select a channel (1, 2 or 3) using the [D2] switch. The channel
function allows the receiver to identify each remote sensor. The main unit can receive up to 3
different remote channels. The preferred channel number (1, 2 or 3) for each individual remote
sensor can be assigned. However, channel 1 is used for collecting data from outdoors and
activating the weather forecast symbols. If you only have one remote sensor, please set it at
channel 1 and place it outdoors.
3. Select whether the sensor will display the temperature in Celsius or Fahrenheit degrees by
pressing [D1].
4. Press the TX button [D3] to synchronize the sensor with your new settings. The icon
at [C2].
5. Insert 2 x AA batteries at the back of the main unit.
Note: the SM1800 comes with one main unit and one remote sensor. If you wish to buy additional
sensors please refer to the section ACCESSORIES at the end of this manual. SM1802 comes with 2
sensors, SM1803 comes with 3 sensors.
SYNCHRONIZATION
Automatic Learn Function
1. The Learn function executes automatically and runs for approximately 2 minutes when the
batteries are first installed in the receiver.
2. Within these 2 minutes, the main unit picks up the temperature & humidity signals from the remote
sensor and displays the readings. If you only have one remote sensor, the main unit will be
automatically synchronized with the channel set on the remote sensor.
6
D1 – C/ F button: to select oC or oF display.
o o
D2 – Channel selection switch: to set the
sensor unit to channel 1, 2 or 3.
D3 – TX button: to synchronize the remote sensor with
new C/ F or channel settings.
o o
*** Located at the back of the sensor unit, inside the
battery compartment.

POWER SUPPLY

Main Unit
SETTINGS
Copyright © Lexibook 2008
Remote
Sensor
5
will appear
