teutonia FUN SYSTEM Bedienungsanleitung Seite 12

INT FUN SYSTEM
Height-Adjustable, Foldable Handle
Applying the Parking Brake
the brake has locked securely. You can release the brake
by depressing the brake lever 2.
Attaching and removing the hood and/or cot
Place the top part on the frame in such a way that the bar
1 on each side of the base clicks into the correct slots 2.
Then slide the top part to the block. The catches then
lock automatically (the catch must "click").
Warning:
Before use, please check that the attachment and
seating unit are correctly clicked into place. The top part
is secure when the red area on the release mechanism
can no longer be seen. To remove the top part, push the
release lever 3 downwards until the lever locks (red area
is visible). Then pull the top part out of the slots and
remove it.
12
To change the height of the
handle, press in the adjusting
buttons on both sides of the
handle.
The brake is activated by
pushing down the long brake
lever 1. If it is difficult to
apply the brake, wheel the
stroller back and forth a few
centimetres so that the brake
bars engage properly in the
wheel rim. Make sure that
How to use the hood
Push the insert pieces for the hood joints into the cor-
responding openings on the armrest or on the carry-cot.
Attention: You must secure the press studs on the back
end of the cover onto the rear of the backrest as the co-
ver is also used as a protection against falling out.
If you need to remove the hood, undo the press studs on
the rear of the backrest; press the release buttons on
the insert pieces of the hood joints and pull the joints out
of the openings. You can open the zip at the top of the
hood for ventilation.
Adjusting the Backrest
Pull the grip 1 upwards and
move the backrest 2 into the
required position.
make sure that the backrest
re-engages properly.
Please
