Folding the chassis
Simultaneously pull up both tensioning sleeves 1 on both
sides as far as they can go and at the same time press
the safety button on the right tensioning sleeve.
Then press the handle 2 down. Now you can additionally
make the storage dimensions smaller by folding down
the upper part of the handle.
Assembling and removing the wheels
Removing the swivel wheel
Before assembling or remo-
ving the wheels, press the
locking spring 1. When as-
sembling the wheels, make
sure that the locking spring
engages properly.
Assembling the wheels
Swivel wheel
Swivel wheel unlocked
We recommend that you do not lock the wheels while
moving as this will give a more comfortable ride.
Seat cover
The seat cover can be completely removed from the seat
unit in order to be washed. To do this, press the press
studs on the seat unit.
The middle seat or reclining surface is designed as a
two-way seat. Release the side zips, pull the cover over
at the head end and the belt on the other side and
re- attach the centre piece on the sides.
Attention: When fitting the seat cover, please pull the
end of the 5-point harness back through the matching
openings without twisting it.
FUN SYSTEM
Swivel wheel locked
