AP24
24

Technical data

Mechanical data
Housing
Color
Elektrische Daten
Operating voltage
Current consumption
Display/dispaly range
Special character
Status display
Keys
Bus connection
Type of connection
Ambient conditions
Ambient temperature
Storage temperature
Relative humidity
Protection category

7.3 Mating connector M8 bus terminator

For the fieldbus to function, a terminating resistor is required (120 Ohm).
• Accessory SIKO art. no. "BAS-0005" (pin 4 pin).
For multiple remote displays on one bus: connect terminating plug to Bus-
Out of the last bus station (see chapter 4.2).
For one remote display: connect terminating plug to Bus-Out (see chap-
ter 4.2).
8 Technical data
reinforced plastic
black RAL 9005
24 V DC ±20 %
~20 mA
5-digit LCD 7-segment,
~7 mm height
left arrow, right arrow, 'incre-
mental measurement'
two-color LED (red/green)
acknowledgment, paramete-
rization
RS485
2x M8 plug connectors
(A-coded)
grounding via flat connector
6.3 mm
0 ... 60 °C
-20 ... 80 °C
IP54, IP65
AP24 · Date 12.05.2015 · Art. No. 85833 · Mod. status 171/15
Additional information
connector thread / PE metal con-
nection
Additional information
if operated with LEDs, additional
~3 mA per LED
decimal points, 2 rows, special
characters
position status, configurable
no galvanic isolation
4-pole, 1x socket, 1x pin
Additional information
condensation inadmissible
EN 60529, only with mating con-
nector
