HOW TO OPERATE WITH YOUR
ALAN 48 EXCEL MULTI
1. Screw the microphone plug into the microphone jack.
2. Make sure your antenna is securely connected to the antenna connector.
3. Make sure the SQUELCH control is turned fully conterclockwise.
4. Turn on the unit and adjust the volume control.
5. Select your desired channel through the "UP/DN" buttons on the microphone.
6. To transmit, press the PTT button and speak with a normal tone of voice.
7. To receive, release the PTT button.

FREQUENCY BAND SELECTION

The frequency bands must be chosen according to the country you are in.
Procedure:
1. Switch off the unit.
2. Turn it on while pushing the "N.K." button.
3. Rotate the "CHANNEL" knob and select the desired frequency band (see the chart
here below).
4. To fix your selection, press the "LOCK" button.
NOTE1: If you select a frequency band which operates in FM mode only, the
"AM/FM" control activates the LCR function (Last Channel Recall).

FREQUENCY BAND CHART

Displayed digits
I
I2
D
D2
EU
EC
E
F
UK
ATTENTION!
The frequency band allowed all over Europe is 40CH FM 4W (EC) – See the
"Restrictions on the use" table.
Country
Italy 40 CH AM/FM 4Watt
Italy 34 CH AM/FM 4Watt
Germany 80 CH FM 4Watt / 12 CH AM 1 Watt
Germany 40 CH FM 4Watt / 12 CH AM 1 Watt
Europe 40 CH FM 4Watt / 40 CH AM 1 Watt
CEPT 40 CH FM 4Watt
Spain 40 CH AM/FM 4Watt
France 40 CH FM 4Watt / 40 CH AM 1 Watt
England 40 CH FM 4Watt English frequencies +
+ EC 40 CH FM 4Watt CEPT frequencies
