Read the operating instructions and the enclosed brochure „Guarantee
!
and additional notices" completely. Follow the instructions they
contain. Safely keep these documents for future reference.
Function / application
The mechanical distance measuring wheel is designed for use on straight lines
and curves. The mechanical measuring wheel delivers accurate measured values
when measuring distances of up to 9,999.9 m. The moving pointer shows the
exact start and end positions. The telescopic handle makes the distance
measuring wheel easy to carry.
1
2
3
6
1
Non-slip handle
2 Telescopic handle
3 Measuring wheel with
0.5 m circumference
4 Mechanical counter
06
GB
5
4
7
5
Delete measured value
6 Stand (fold-out)
7 Moving pointer for
start and end position
