To measure from wall to spot
4
1. Position the device with the rear of
the measuring wheel against the
wall.
2. Move the measuring wheel straight
to the marked spot.
3. Read off the measured value and
add the radius of the wheel.
To measure from spot to spot
5
1. Position the pointer (7) on the first
marked spot.
2. Move the measuring wheel straight
to the other marked spot.
3. Read off measured value.

Technical data

Accuracy
Range
Circumference of measuring wheel
Measuring wheel diameter
Measuring wheel radius
Dimensions (W x H x D)
Weight
08
GB
Subject to technical alterations. 09.2014
R + Measurement
Measurement
± 0.1%
0 – 9,999.9 m
500 mm
159 mm
79.5 mm
124 x 1100 x 159 mm (extended) /
124 x 550 x 159 mm
550 g
