Delete measured value
1
The mechanical counter is set to
zero by pressing button 5.
To measure from wall to wall
3
1. Position the device with the rear of
the measuring wheel against the
wall.
2. Move the measuring wheel straight
to the other wall.
3. Read off the measured value and
add the diameter of the wheel.
To achieve accurate measurement results, the guide bar must be held
!
at the same angle during the entire measurement. A vertical position
is recommended.
Pull out telescopic handle
2
The height of the telescopic handle
can be adjusted at two points.
2.
1.
+
R Measurement
