4

Commissioning

4.1

Checking the requirements for commissioning

The fitting will be ready for commissioning when the tasks described in the "Installation" chapter have been completed.
• The connections of the fitting to the heating system and the make-up system are made.
• The fitting is filled with water and vented.
• The regional overall water hardness is known.
– Cartridge capacity for treating water
Note!
• Contact the local water supplier for the regional overall water hardness.
• Optionally use the measuring equipment for determining the regional overall water hardness.
• For calculating the cartridge's capacity, see chapter 2.1 "Calculating the cartridge capacity " on page 6 .
4.2

Execution

Start the system. Proceed as follows:
1. Slowly open the ball valve at the fitting's outlet.
– If required, the heating system is filled with treated
water.
2. Record the water level shown at the water meter.
– User-provided water meter or Fillset.
– Optional "Fillmeter" water meter.
3. Record the value taken from the water meter in the supplied
machine log.
– The meter count provides information about the next
cartridge replacement.
4. Attach the Fillsoft set-up adhesive label at the fitting's filter
housing.
Complete the Fillsoft set-up and enter the information on the
label:
5. Identify the used variant for water treatment.
• Fillsoft softening
• Fillsoft Zero desalinating
6. Enter the cartridge capacity information.
The fitting is commissioned. The heating system is supplied with treated water from the make-up system.
