Operating instructions
Powerbank, 2600 mAh
Item no. 1382128
Intended use
This product is a portable rechargeable spare battery and can be used to charge the
rechargeable batteries of mobile devices such as smartphones. The internal, integrated
rechargeable battery can be charged via USB.
For safety and approval purposes (CE), you must not rebuild and/or modify this product. If you
use the product for purposes other than those described above, the product may be damaged.
In addition, improper use can cause hazards such as short circuiting, fire, electric shock etc.
Read the instructions carefully and keep them for future reference. Make this product available
to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company
names and product names are trademarks of their respective owners. All rights reserved.
Delivery content
• Powerbank
• Micro-USB cable (approx. 24 cm long)
• Operating instructions
Up-to-date Operating Instructions:
1. Open www.conrad.com/downloads in a browser or scan the displayed
QR code.
2. Select document type and language and enter the item number into
the search field. After submitting the query you can download displayed
records.
Description of symbols
This symbol indicates health risks e.g. due to electric shock.
This symbol informs you about specific risks when handling, operating or using the
product.
The "arrow" symbol indicates special remarks and notes for operation.
Safety instructions
Read the operating instructions carefully and especially observe the safety
information. If you do not follow the safety instructions and information on
proper handling in theses operating instructions, we assume no liability for
any resulting personal injury or damage to property. Such cases will invalidate
the warranty/guarantee.
• The device is not a toy. Keep it out of the reach of children and pets.
• Do not leave packaging material lying around carelessly. These may become
dangerous playing material for children.
• Protect the product from extreme temperatures, direct sunlight, strong jolts, high
humidity, moisture, flammable gases, vapours and solvents.
• Do not place the product under any mechanical stress.
• If it is no longer possible to operate the product safely, take it out of operation and
protect it from any accidental use. Safe operation can no longer be guaranteed
if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor ambient conditions or
- has been subjected to any serious transport-related stresses.
• Please handle the product carefully. Jolts, impacts or a fall even from a low height
can damage the product.
• Also observe the safety and operating instructions of any other devices which are
connected to the product.
• Never leave the product unattended during use.
• Never use the product immediately after it has been brought from a cold room
into a warm one. The condensation generated could destroy the product. Allow
the device to reach room temperature before connecting and using it. This may
take several hours.
• The housing of the power bank gets warm during use. Ensure sufficient ventilation.
Never cover the product!
Version 01/16
• Make sure the cable connected to the power bank does not get jammed, bent or
damaged by sharp edges.
• Do not use force to connect USB plugs. USB plugs can be plugged into a USB
socket only one way.
• Do not and store the product in environments with strong electrostatic charges or
strong magnetic fields.
• The rechargeable battery is permanently built into the product and cannot be
replaced.
• Never damage the rechargeable battery. Damaging the casing of the rechargeable
battery might cause an explosion or a fire!
• Never short-circuit the contacts of the rechargeable battery. Do not throw the
rechargeable battery or the product into fire. There is a danger of fire and
explosion!
• Charge the rechargeable battery regularly, even if you are not using the product.
Due to the rechargeable battery technology being used, you do not need to
discharge the rechargeable battery first.
• Never charge the rechargeable battery of the product unattended.
• When charging, place the product on a surface that is not heat-sensitive. It is
normal that a certain amount of heat is generated during charging.
• Consult a professional if you require assistance with product operation, safety
or connection.
• Maintenance work, adjustments and repairs may be carried out only by a
professional or at a specialist workshop.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.
Operating elements
1 Micro USB port IN: DC 5V
2 USB-A port
3 Power LED

Operation

Verify that your mobile device's connection values correspond with the product's
connection values (see technical data).
Always read your mobile device's user manual.
Do not short-circuit the USB input/output of the power bank.
The USB cable cannot be used to transfer data.
It is not possible to charge the internal rechargeable battery and a mobile device
at the same time. Always use the charging input (1) or the charging output (2)
respectively.
The power bank contains high-quality smart charging technology that adjusts the
charging performance accordingly. The charging current used can vary within a
range from 0.5 A to 0.8 A.
In order to charge the internal battery, do not connect the USB port of a keyboard
or USB hub without separate power adapter, as the current provided would not
be sufficient.
Fully charge the internal battery every three months in order to maintain full
function performance.
a) Charging the internal rechargeable battery
• Connect the micro USB plug of the provided cable to the IN:DC 5V micro USB port (1) of
the power bank.
• Connect the type A plug of the USB cable to the USB port of a computer or other USB power
source, e.g. a USB power adapter. Latter one must provide a current of at least 0.5 A.
• Charging starts once the USB power source supplies current. The power LED (3) starts
flashing.
• Fully charge the power bank for approx. 7 to 8 hours before first time use.
After that, any further charging of the completely discharged battery will take approx. 3.5 to
4.5 hours. The actual charging time depends on the charging condition of the rechargeable
battery and the available charging current.
(charging input)
1
OUT: DC 5V (charging output)
(hidden)
2
IN:DC 5V
3
OUT:DC 5V
