• Consult an expert when in doubt about operation, safety or connection of the
device.
• Maintenance, modifications and repairs are to be performed exclusively by an
expert or at a qualified shop.
• If you have questions which remain unanswered by these operating instructions,
contact our technical support service or other technical personnel.

Operation

a) Connection
• Connect the Micro-USB plug on the included USB cable to the Micro-USB socket on the
back of the charger.
• The charger can be supplied with power via the included power adapter or via a USB port
on your computer.
- Power adapter: Connect the USB-A plug on the USB cable to the corresponding socket on
the power adapter. Then plug the power adapter in to a common household power outlet.
- Computer: Connect the USB-A plug on the USB cable to a free USB port on your computer.
• The product is now ready for use.
b) Charge rechargeable batteries
• Connect up to two 9 V rechargeable block batteries to the charger's push button-shaped
contacts. Batteries can be connected only one way. Do not use any force.
• The charging slot LED lights up red while the battery is charging.
When the LED flashes red, it indicates that the rechargeable battery or the charger
is defective. In this case, disconnect the product from the power supply.
For testing purposes, insert a new, functional rechargeable battery or test the
rechargeable battery in question with another charger.
Cease use of the charger if it turns out to be defective.
• The LED lights up green when the rechargeable battery is fully charged.
• Remove the rechargeable batteries and disconnect the charger from the power supply when
charging is complete.
c) Charge a USB device
Always turn off the desired device before connecting it to the USB port.
Make sure the connection is correct. If the product is not connected properly,
it could overheat or cause an electric shock or fire.
The current consumption of the USB device may not exceed 1000 mA when
connected to the power adapter.
If the charger is connected to your computer, the maximum current
consumption of the USB device depends on the output current of your
computer's USB port.
• Connect a USB device to the USB charging port on the front of the charger.
• Your USB device is now charging. Should you wish to operate the USB device, you may
turn it on now.
• Turn off the USB device and disconnect it from the USB charging port when it is fully charged.
• Remove the charger from the power supply when charging is complete.
d) Notes
• If the current consumption of the USB device deceeds 500 mA, you can charge up to two 9 V
rechargeable block batteries simultaneously.
• If the current consumption of the USB device is between 500 - 1000 mA, you cannot charge
a 9 V rechargeable block battery simultaneously.
• If the charger is connected directly to your computer, the computer's USB port supplies
current to the USB charging port. As a rule, current supply is either 500 mA (USB 2.0) or
900 mA (USB 3.0).
• If the charger is connected directly to your computer and you are charging a USB device via
the USB charging port, you cannot charge a 9 V rechargeable block battery simultaneously.

Maintenance and cleaning

• This product does not require maintenance. There are no components located inside the
product you need to maintain. Never open/dismantle the product. Have maintenance and
repairs done by qualified experts or repair shops only.
• Before cleaning, disconnect the product from the power supply, unplug all cables and remove
the rechargeable batteries.
• To clean the product, a dry, soft and clean cloth is sufficient. You can use a long-haired, soft
and clean brush and a vacuum cleaner to remove dust.
• Never use any aggressive cleaning agents or chemical solutions as they may cause damage
to the housing or cause the product to malfunction.
Disposal
a) Product
Electronic devices are recyclable waste and must not be disposed of in the
household waste.
At the end of its service life, dispose of the product according to the relevant
statutory regulations.
Remove any inserted rechargeable batteries and dispose of them separately from
the product.
b) Rechargeable batteries
You as the end user are required by law (Battery Ordinance) to return all used rechargeable
batteries. Disposing of them in the household waste is prohibited.
Contaminated rechargeable batteries are labelled with this symbol to indicate that
disposal in the domestic waste is forbidden. The designations for the heavy metals
involved are: Cd = Cadmium, Hg = Mercury, Pb = Lead (name on rechargeable
batteries, e.g. below the trash icon on the left).
Used rechargeable batteries can be returned to collection points in your municipality, our stores
or wherever rechargeable batteries are sold.
You thus fulfil your statutory obligations and contribute to the protection of the environment.

Technical data

Suitable for ............................................... u p to two rechargeable 9 V block batteries
Input voltage/current (power adapter) ...... 100 – 240 V/AC, 50/60 Hz, 130 mA
Output voltage/current (power adapter) . ... 5 V/DC, max. 1000 mA, 5 W
Charging current . ...................................... max. 70 mA
Trickle charging current ............................ 7 mA
Standby power consumption .................... max. 0.25 W
Operating conditions . ................................ 0 to +35 ºC, 20 – 85 % RH
Storage conditions . ................................... -20 to +60 ºC, 10 – 90 % RH
Dimensions (W x H x D) ........................... 85 x 18 x 43 mm
Weight ...................................................... 38 g (charger), 43 g (power adapter)
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent the
technical status at the time of printing.
© Copyright 2014 by Conrad Electronic SE.
(NiMH/NiCd)
