Marking Objects
Detected objects can be marked as required. For this, remove
the pencil 11 from the measuring tool and carry out the scan
as usual. Once you have found the limits or the centre of an ob-
ject, simply mark the sought after location through the marking
opening 2.
"AutoCal" Calibration Indicator
When the check mark behind the "AutoCal" calibration indica-
tor g flashes over a longer period or if it is not displayed any-
more, reliable scanning is no longer possible. In this case, send
in the measuring tool to an authorised Bosch after-sales serv-
ice agent. Exception: In the detecting wooden objects' func-
tion, the "AutoCal" calibration indicator g goes out as long as
the "ZOOM" button 4 is not pressed.

Maintenance and Service

Maintenance and Cleaning

When the measuring indicator f continuously shows an ampli-
tude even though there is no metal object in the vicinity of the
measuring tool, the measuring tool can be calibrated manually.
For this, remove all objects in the vicinity of the measuring tool
(including wrist watches or rings of metal) and hold the meas-
uring tool up in the air. With the measuring tool switched off,
press both the "on/off" button 7 and the wood-detection but-
ton 5 until the illuminated ring 1 lights up red and green at the
same time. Then release both buttons. When the calibration
process was successful, the measuring tool will start over after
a few seconds and is then ready for operation.
Wipe away debris or contamination with a dry, soft cloth. Do
not use cleaning agents or solvents.
In order not to affect the measuring function, decals/stickers or
name plates, especially metal ones, may not be attached in the
sensor area 9 on the front or back side of the measuring tool.
Do not remove the felt pads 8 on the back side of the measur-
ing tool. Replace the felt pads when they are damaged or used.
For this, completely remove the felt pads and glue the new felt
pads onto the same spots.
Store and transport the measuring tool only in the supplied
protective pouch.
If the measuring tool should fail despite the care taken in man-
ufacturing and testing procedures, repair should be carried out
by an authorised after-sales service centre for Bosch power
tools. Do not open the measuring tool yourself.
In all correspondence and spare parts orders, please always in-
clude the 10-digit article number given on the type plate of the
measuring tool.
