18 | English

Technical Data

Digital Detector
Article number
Maximum scanning depth*:
– Ferrous metals
– Non-ferrous metals (copper)
– Copper conductors (live)**
– Wood
Automatic switch-off after approx.
Operating temperature
Storage temperature
Battery
Battery
Operating lifetime
(alkali-manganese batteries) approx.
Weight according to
EPTA-Procedure 01/2003
* depends on material and size of objects as well as material and condi-
tion of structure
** less scanning depth for wires/conductors that are not "live"
In terms of accuracy, the measuring result can be inferior in case
of unfavourable surface quality of the base material.
Please observe the article number on the type plate of your measuring
tool. The trade names of the individual measuring tools may vary.
Assembly

Inserting/Replacing the Battery

Using alkali-manganese or rechargeable batteries is recom-
mended for operation of the measuring tool.
To open the battery lid 10, press the latch 12 in the direction
of the arrow and fold up the battery lid. Insert the supplied bat-
tery. Pay attention that the polarity is correct, according to the
representation on the inside of the battery lid.
When the battery low indicator k lights up on the display,
measuring is still possible for approx. 1 hour when using alkali-
manganese batteries (lower battery service life for rechargea-
ble batteries). When the battery low indicator k flashes, meas-
uring is possible for approx. 10 minutes. When the battery low
indicator k and the illuminated ring 1 (red) flash, measuring is
no longer possible and the battery/rechargeable battery must
be replaced.
1 609 929 X41 | (28.10.10)
PDO Multi
3 603 K10 000
80 mm
60 mm
40 mm
20 mm
5 min
–10 °C ... +50 °C
–20 °C ... +70 °C
1 x 9 V 6LR61
1 x 9 V 6F22
0.25 kg
Bosch Power Tools
6 h
