3. Phottix Strato transmitters will trigger the
Atlas II on Channels 1 to 4.
4. The Atlas II will not trigger Strato II Multi or
Odin receivers.
5. The Atlas II will trigger Strato receivers.

Inserting Batteries

1. Press the battery cover in while pushing it
away from the Atlas II. The battery cover will
snap open.
2. Lift the battery cover.
3. Insert AA batteries as shown.
4. Close the battery cover and push the cover
back into the locked position.
Test / Shutter Button
1. The Test / Shutter Button will test re remote
4
ashes/strobes or take a photo as a wireless
remote when the Phottix Atlas II is set in Tx
(transmit mode).
2. The Test / Shutter Button takes a photo when
used as a wired remote and connected to a
camera with a Phottix Accessory Cable.
3. To Test: Press the Test / Shutter Button –
remote ashes connected to Phottix Atlas II
transceivers set in Rx (receive mode) and on the
same channel, will re.
For Remote Use See:
wireless remote
as a wired remote

Status LED

1. The Status LED on the front of the Phottix
Atlas II will ash green when it is ready to
Using the Atlas II as a
Using the Atlas II
and
below.
