Connecting to the camera PC Sync
Port*
(A ash on the camera hot shoe, the
Atlas II connected to the camera PC
Sync port)
1. Turn o the camera, ash, and the Phottix
Atlas II transceiver.
2. Connect a compatible cable to the Phottix
Atlas II Flash in/out port.
3. Connect the opposite end of the cable to the
camera's PC Sync port.
4. Set the Transmit / Receive Mode Switch on
the Atlas II to Tx (transmit mode).
5. Turn on the camera and Phottix Atlas II. Set
the camera to Manual mode.
6. Releasing the camera shutter will re the hot
En
s h o e m o u n t e d
transmitting a signal from the camera to the
PC Sync attached Phottix Atlas II. The Atlas II
will trigger any remote ashes or strobes
connected to Phottix Atlas II transceivers on
the same channel set in Rx (receive) mode.
*On compatible cameras
U s i n g t h e A t l a s I I a s a w i r e l e s s
remote*
1. Turn o the camera and the Phottix Atlas II
transceiver.
2. Attach the correct Phottix Accessory Cable
for your camera make and model to the
Shutter Release Port on the Atlas II.
3. Attach the other end of the cable to the
camera' s remote port.
INSTRUCTION MANUAL
a s h , s i m u l t a n e o u s l y
