Connecting to the camera hot shoe
1. Turn o the camera and Phottix Atlas II
transceiver.
2. Slide the Atlas II transceiver into the
camera's hot shoe mount.
3. Turn the Atlas II locking ring until tight.
4. Set the Transmit / Receive Mode Switch on
the Atlas II to Tx (transmit mode).
5. Turn on the Phottix Atlas II and the camera.
6. Set the camera and ash to Manual mode.
Connecting a ash
to the Atlas II hot shoe
1. Turn o the ash and the Phottix Atlas II
transceiver.
6
2. Slide the ash into the transceiver' s hot shoe
mount.
3. Lock the ash with the ash' s locking
mechanism.
4. Set the Transmit / Receive Mode Switch on
the Atlas II to Rx (receive mode).
5. Turn on the Phottix Atlas II and ash.
6. Set the ash to Manual mode.
* It is not unusual for the ash to discharge
once after turning on the Phottix Atlas II.
Connecting a ash
or studio light by cable
1. Turn o the ash/strobe and the Phottix
Atlas II transceiver.
