transmit or receive signals. The LED will turn
solid red when a signal is sent or received.
2. When the battery power is very low, the
Status LED will ash green light every 0.5
seconds. Please change the batteries (see
above).
Turning units on/o
1. To turn on the Phottix Atlas II – move the
power switch to the "ON" position.
2. To turn o the Phottix Atlas II – move the
power switch to the "OFF" position.
Setting Transmit or Receive Mode
1. Set the Transmit / Receive Mode Switch to Tx
for transmit mode. This can be used on a
camera hot shoe to trigger remote ashes or to
take photos when using the Atlas II as a wire-
En
less remote shutter release.
2. Set the Transmit / Receive Mode Switch to
Rx for receive mode. This can be used to
trigger remote ashes or cameras when using
the Atlas II as a wireless remote shutter release.
Setting Channels
1. The Phottix Atlas II has four channel settings.
2. Move the Channel Selector Switch to 1, 2, 3,
or 4 to select a channel.
3. Make sure all Phottix Atlas II transceivers,
b o t h o n t h e c a m e r a a n d a t t a c h e d t o
ashes/strobes, are on the same channel.
4. Atlas II transceivers in Rx (receive) mode set
to channels di erent from the channel set on
the Atlas II set to Tx (transmit) mode will not
re.
