NOTICE:
For new growth, a wide sweeping is suitable
for the stems fed directly into the cutting blade. For older
growth, a sawing movement is good for trimming the
thicker stems. A non-powered hand saw or pruning saw is
suggested for trimming the large stems first.
Top Cutting
Use a wide sweeping motion. A slight downward tilt of the
cutting blades in the direction of motion gives the best
cutting results. For better cutting effect, you might as well
use the string to guide the hedge level as Fig. G shown.
Side Cutting
When trimming the sides of the hedge, begin at the
bottom and cut upwards as Fig. H shown.
Sawing Function
Although the blade gap allow wood to be cut up to Ø22mm,
the tip of the blade is designed to cut wood up to Ø26mm
(Fig. I). If a radical cut is necessary, cut a little at a time in
several stages.
Tip Protector
The tip protector (Fig. A-8) makes cutting near the ground
or along walls easier while protecting the special cutters
from damage.

MAINTENANCE

WARNING:
When servicing, use only identical
replacement parts. Use of any other parts may create a
hazard or cause product damage. To ensure safety and
reliability, all repairs should be performed by a qualified
service technician.
WARNING:
To avoid serious personal injury, always
remove the battery pack from the product when cleaning
or performing any maintenance.
CLEANING
◾
Use a soft brush to remove debris from all air intakes
and cutting blade.
◾
To remove pitch and other sticky residue, spray the
blades with resin solvent. Run the motor briefly so that
the solvent is evenly distributed.
◾
Wipe the surface with a dry cloth.
WARNING:
Never use water for cleaning your
trimmer. Avoid using solvents when cleaning plastic
parts. Most plastics are susceptible to damage from
various types of commercial solvents. Use clean clothes to
remove dirt, dust, oil, grease, etc.
56 VOLT LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E
SHARPENING THE CUTTING BLADE
1. Start and stop your hedge trimmer until the cutter
blade and the guard are slightly offset as Fig. J shown.
Fig. J parts description see below:
J-I Cutter Tooth
J-2 Guard Tooth
2. Remove the battery pack from you hedge trimmer.
3. Clamp the blade assembly in a vise and file the
exposed cutting surface of each blade tooth. Remove
as little material as possible.
4. Remove the hedge trimmer from the vise and adjust
the unsharpened blade exposed. Repeat the above
procedures until all the blade teeth sharpened.
NOTICE:
Do not operate your hedge trimmer with dull or
damaged cutting blades. This may cause overload and
will give unsatisfactory cutting results.
LUBRICATING THE BLADE
For best operation and longer blade life, lubricate the
hedge trimmer blade with light weight machine oil before
and after each use.
Remove the battery pack and lay the trimmer onto a flat
surface. Apply the oil along the edge of the top blade as
Fig. J shown.
NOTICE:
For extended using period, oil the blade during
cutting operation.
WARNING:
Do not oil while the hedge trimmer is
running.
TRANSPORTING AND STORING
◾
Always place the blade guard on the blade before
storing or transporting the hedge trimmer. Use caution
to avoid the sharp teeth of the blade.
◾
Clean the hedge trimmer thoroughly before storing.
◾
Store the hedge trimmer indoors, in a dry place that is
inaccessible to children.
◾
Keep away from corrosive agents such as garden
chemicals and deicing salts.
WARNING:
Blades are sharp. When handling the
blade assembly, wear non-slip, heavy-duty protective
gloves. Do not place your hand or fingers between blades
or in any position where they could get pinched or cut.
NEVER touch blades or service the unit with battery pack
installed.
