IKAR HWB 1.8 DW Gebrauchsanleitung Seite 8

D GB ES FR
Erforderlicher Kantenabstand bei horizontalem Einsatz
nach ANSI/ASSE Z359.14-2014
Setback distance required for horizontal use acc. to ANSI/ASSE Z359.14-2014
18
IT PT NL
Setback distance required for horizontal use
type *
HWB 1.8
HWB 1.8 DW
HWDB 2
HWB 2
HWB 2.8
HWB 3.5
HWPB 3.5
HWPS 3
HWPS 4,5
HWS 4,5
HWPB 5,5
HWPB 7
HWPB 9
HWS 6
HWS 9
HWPS 6
HWPS 9
HPB 7
HPS 6
HWS 12
HWS 18
HWS 24
HWPS 12
HWPS 18
HWPS 24
H 12
H 18
H 24
H 33
HPB 12
HPS 12
HPS 18
* SRL Performance Data: Average Arresting Force 3,4 kN (765 lbs)
PL RO DK SE
setback distance
30 cm/ 12 in
40 cm / 16 in
50 cm / 20 in
70 cm / 30 in
8
FI NO HU SK GR
