4. Specifications
DVB-S / S2 / S2X
ƒ DVB-S Frequency range: 950 - 2150 MHz
ƒ DVB-S LNB Voltage: 13/18 V, max. 300 mA
ƒ DVB-S LNB Power: Evaluation of LNB power (mA)
ƒ DVB-S Level range: 35 ~ 90 dBμV
ƒ Input resistance: 75 Ω
ƒ Measurement of Ultra HD signals
ƒ Unicable I & II (EN 50494 / EN 50607)
ƒ DiSEqC 1.0 / 1.1 / 1.2 / USALS (Automatic detection of DiSEqC 1.0)
ƒ Automatic satellite detection (NIT)
ƒ Calculation of angle of rotation and inclination of the antenna
ƒ Search mode: Automatic, manual, blind scan
ƒ LNB Short circuit protection with LED indicator
ƒ Display of signal strength / quality, dBm, CNR, BER
ƒ Spectrum and constellation analysis
ƒ Cable identification at Quattro LNB (Transponder control)
DVB-T / T2
ƒ Frequency range: 44 - 870 MHz
ƒ Level range: 30 ~ -100 dBμV
ƒ Display of signal strength / quality, BER, PER, CNR
ƒ Spectrum and constellation analysis
ƒ Automatic signal identification
ƒ Code Rate: DVB-T: 1/2, 2/3, 3/4, 5/6, 7/8
ƒ Code Rate: DVB-T2: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6
ƒ Modulation DVB-T: QPSK, 16 QAM, 64 QAM
ƒ Modulation DVB-T2: QPSK, 16 QAM, 64 QAM, 256 QAM
ƒ Bandwidth DVB-T: 6, 7 and 8 MHz
ƒ Bandwidth DVB-T2: 1.7, 6, 7 and 8 MHz
DVB-C / C2
ƒ Frequency range: 44 - 870 MHz
ƒ Level range: 30 ~ -100 dBμV
ƒ Display of signal strength / quality, BER, PER, CNR, symbol rate
ƒ Spectrum and constellation analysis
ƒ Tilt display
ƒ Modulation DVB-C: 16 QAM to 256 QAM
ƒ Modulation DVB-C2: 16 QAM to 4096 QAM
ƒ RF input level range: 30 ~ 100 dbμV
