GB
9.1. Longitudinal cuts (Figure 20)
Longitudinal cutting is when you use the saw to cut
along the grain of the wood.
Place the parallel stop (24) to the left of the blade
(25), as far as possible, for the width required.
Lower the blade guide (11) down to the
workpiece (see 7.5).
Switch on the saw.
Press the edge of the workpiece with your right
hand to hold it securely against the parallel stop
(24) and flat on the table (15).
Guide the workpiece along the parallel stop (24)
and through the blade (26) at a uniform speed.
Important: Long workpieces must be secured
against falling off at the end of the cut (e.g. with a
roller stand etc.)
9.2. Making angular cuts (Fig. 19)
Set the saw table to the desired angle (see 8.3).
Carry out the cut as described in 9.1.
9.3. Freehanded cuts (Figure 21)
One of the most outstanding features of a bandsaw
is the ease with which it allows you to make curved
cuts and radii.
Lower the blade guide (11) to the workpiece (see
7.5).
Switch on the saw.
Hold the workpiece securely on the table (15)
and guide slowly through the blade (26).
Freehanded cuts should be made at low feed
speed so that you can guide the blade (26) along
the required line.
It often pays to first cut off surplus curves and
corners up to about 6 mm from the cutting line.
In the case of curves which are too tight for the
blade to cut correctly, it can help to make a
series of close-lying cuts at right angles to the
curved line. When you saw the radius the
material will simply drop off.
10. Transport
To transport the bandsaw, hold the supporting foot
(5) with one hand and the frame (25) with the other
hand. Important! Never use guards to lift or transport
the equipment.

11. Maintenance

Caution! Pull out the power plug first.
Remove dust and dirt regularly from the
bandsaw. Cleaning is best carried out with a fine
20
25.10.2007 15:36 Uhr Seite 20
brush or a cloth.
Do not use caustic cleaning agents for cleaning
plastic.

12. Ordering replacement parts

Please quote the following data when ordering
replacement parts:
Type of machine
Article number of the machine
Identification number of the machine
Replacement part number of the part required
For our latest prices and information please go to
www.isc-gmbh.info

13. Disposal and recycling

The unit is supplied in packaging to prevent its being
damaged in transit. This packaging is raw material
and can therefore be reused or can be returned to
the raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic.
Defective components must be disposed of as
special waste. Ask your dealer or your local council.
