6 CONTROLS
GB

6.12 BACKLAPPING LEVER

Sets reel rotational direction with three positions:
(A) forward for mowing, (B) reverse for backlapping
and (C) neutral. See the separate cutting unit
operator's manual for an explanation of the
backlapping procedure.

6.13 CUTTING UNIT SWITCHES

To commence cutting ensure speed limiter is in
mow position. Push bottom of the rocker switch (G)
to activate joystick, lower units and depress foot
switch (A) to start cutter rotation. Push top of rocker
switch to stop cutter unit rotation and de-activate
joystick. (Cutting units stop rotating automatically
when raised.)
