1.7. Installing the video door intercom
Prepare casing for cable feed
Place device in casing
Place decorative ring cap over screw and screw device
to casing.
Screw on decorative cap
The example is for surface-mounting installa-
tion. The device can also be flush-mounted.
In this case the matching flush-mount casing
is mounted in the wall opening or cavity wall
cutout and the device fixed as shown.
Instructions for myintercom
Introduction
Attach surface-mount casing and connect device
GB
31
