16 | English

Technical Data

Tile laser
Article number
Working range
Angular accuracy
Operating temperature
Storage temperature
Relative air humidity, max.
Laser class
Laser type
C
6
Batteries
Operating life time, approx.
Weight according to
EPTA-Procedure 01/2003
Dimensions
1) The working range can be decreased by unfavourable environmental
conditions (e.g. direct sun irradiation).
Please observe the article number on the type plate of your measuring
tool. The trade names of the individual measuring tools may vary.
Assembly

Inserting/Replacing the Battery

Alkali-manganese batteries are recommended for the measur-
ing tool.
To open the battery lid 9, press on the latch 12 and fold the
battery lid up. Insert the batteries. When inserting, pay atten-
tion to the correct polarity according to the representation on
the inside of the battery compartment.
Always replace all batteries at the same time. Only use batter-
ies from one brand and with the identical capacity.
Remove the batteries from the measuring tool when not
using it for extended periods. When storing for extended
periods, the batteries can corrode and discharge them-
selves.
1 609 929 T81 | (6.8.09)
PLT 2
3 603 F64 000
1)
7 m
±0.5 mm/m
+5 °C ... +40 °C
– 20 °C ... +70 °C
90 %
2
635 nm, <2 mW
>2
3 x 1.5 V LR6 (AA)
15 h
360 g
240 x 128 x 59 mm
