Prior to every cut retighten the locking screws
of the stop rails.
For cleaning purposes you can remove the
stop rails from the workpiece stop (40).
Always fasten the movable stop rails on the
equipment again after you have completed
your cleaning work.

6. Operation

6.1 Cross cut 90° and turntable 0°
(Fig. 1–3, 11, 12)
For cutting widths up to approx. 100 mm it is
possible to fi x the saw's drag function with the
locking screw for drag guide (24) in rear position.
If the cutting width exceeds 100 mm you must
ensure that the locking screw for drag guide (24)
is slackened and that the machine head (4) can
be moved.
Move the machine head (4) to its upper po-
sition.
Use the handle (1) to push back the machine
head (4) and fix it in this position if required
(dependent on the cutting width).
Place the piece of wood to be cut against the
workpiece stop (40) and on the turntable (17).
Caution! Lock the material with the clam-
ping device (8) on the fixed saw table (18) to
prevent the material from moving during the
cutting operation.
Clamp flat material in lying position using the
vertical clamping device (position A).
Alternatively, clamp flat material which you
want to cut in upright position using the hori-
zontal clamping device (position B).
Push down the release lever (3) to release the
machine head (4).
Press the On/Off switch (2) to start the motor.
With the drag guide (23) fixed in place: Use
the handle (1) to move the machine head (4)
steadily and with light pressure downwards
until the saw blade (7) has completely cut
through the workpiece.
With the drag guide (23) not fixed in place:
Pull the machine head (4) all the way to the
front and then use the handle (1) to move it
downwards steadily and with light pressure.
Now push the machine head (4) slowly and
steadily to the very back until the saw blade
(7) has completely cut through the workpiece.
When the cutting operation is completed,
move the machine head (4) back to its upper
(home) position and release the On/Off but-
Anl_TE_SM_2534_Dual_SPK7.indb 27
Anl_TE_SM_2534_Dual_SPK7.indb 27
GB
ton (2).
Important! The integral resetting springs will
automatically lift the machine head. Do not simply
let go of the handle (1) after cutting, but allow the
machine head (4) to rise slowly, applying slight
counter pressure as it does so.
6.2 Cross cut 90° and turntable 0° - 45°
(Fig. 1-3, 13, 14)
The crosscut saw can be used to make crosscuts
of 0°- 45° to the left and 0° - 45° to the right in re-
lation to the stop rail.
Release the turntable (17) by undoing the
locking screw (14).
Turn the turntable (17) and scale pointer (15)
to the desired angular setting on the dial (16)
and lock into place with the locking screw
(14). The saw has locking positions at angles
of - 45°, -30°, -22.5°, -15°, 0°, 15°, 22.5°, 30°
and 45°, at which the turntable (17) audibly
clicks into position.
Retighten the locking screw (14) to secure the
turntable (17) in place.
Cut as described in section 6.1.
6.3 Miter cut 0°- 45° and turntable 0°
(Fig. 1–3, 15, 16)
The crosscut saw can be used to make miter cuts
to the left of 0°-45° and to the right of 0°-45° in
relation to the work surface.
If required, dismantle the clamping device
(8) or mount on the opposite side of the fixed
saw table (18).
Move the machine head (4) to its upper po-
sition.
Fasten the turntable (17) in 0° position.
Adjust the miter angle on the machine head
and the stop rail as described under points
5.5 and 5.6.
Cut as described in section 6.1.
6.4 Miter cut 0°- 45° and turntable 0°- 45°
(Fig. 1–3, 17, 18)
The crosscut saw can be used to make miter cuts
to the left of 0°-45° and to the right of 0°-45° in
relation to the work surface, with simultaneous
setting of the turntable from 0°-45° to the left or
0°-45° to the right in relation to the stop rail (dou-
ble miter cut).
If required, dismantle the clamping device
(8) or mount on the opposite side of the fixed
saw table.(18)
Move the machine head (4) to its upper po-
sition.
Release the turntable (17) by undoing the
locking screw (14).
- 27 -
