4.4

Menu items

Last tests
The device displays the last 5000 tests.
A smaller number can be set in the
range
0 - 249.
Selecting the Tests with
Go back with the OK key.
The data sets can be transferred to a PC using the "Diagnostics"
PC software.
Last cal. date
Displays the date of the last calibration and the last accuracy test.
Go back with the Hokey.
Date & time
Displays the current date and the time. Go back with the OK key.
Date (optional)
Displays and sets the date and the date format. Change with
and ; confirm with the OK key.
Time (optional)
Displays and sets the time, the time format and the automatic
changeover from summer to winter time. Change with
; confirm with the OK key.
Select language (optional)
Selects the display language.
Set contrast
Change with and . Go back with the OK key.
M
Check accuracy (optional)
Additional test of the measuring accuracy within the calibration
period
Dräger Alcotest 6820
Back to measurement
Last tests
Last cal. date
Date & time
Set date
Set time
Set language
and .
M
5

Fault

An error message (refer to page 32) will
appear if a device fault occurs.
The number that appears below the
message is used for service functions. If the
fault persists even after the device has been
switched on and off several times and/or the
battery has been removed (for a minimum of 2 seconds) and re-
inserted, contact Dräger.
6

Technical Manual

Further information, e. g. on calibration or the selection of other
measurement units are contained in the Technical Manual.
M
and
M
Fault
Internal
System
ERROR
662
31
