Command overview of the applicable FS20 commands
Command
Aus
= "Off"
Ein (auf Helligkeitsstufe 1...16)
= "On (to brightness stage 1...16)"
Ein (auf alter Stufe)
= "On (to old stage)"
Toggeln (Aus <-> alter Zustand)
= "Toggle (Off <-> old status)"
Dim up
Dim down
Dim up and down
Aktor-Timer programmieren
= "Program actor timer"
Aus für
= "Off for"
Ein (100 %) für (1)
= "On (100 %) for (1)"
Ein (alte Stufe) für (1)
= "On (old stage) for (1)"
Einschaltrampe programmieren
= "Program activation threshold"
Ausschaltrampe programmieren
= "Program deactivation threshold"
Ein (100 %) für (2)
= "On (100 %) for (2)"
Ein (alte Stufe) für (2)
= "On (old stage) for (2)"
Nicht verwendet
= "Not used"
Meaning
A trained dimmer dims down within the stated time
(A switch deactivates immediately)
A trained dimmer dims within the stated time to this stage (a switch activates
immediately)
A trained dimmer dims within the stated time to the last stage used (a switch
activates immediately)
A trained actor switches between deactivated and previous stage
A trained dimmer is increased by one brightness stage
A trained dimmer is decreased by one brightness stage
A trained dimmer dims cyclically between stage 1 and stage 16
The timer of a trained actor is programmed
A trained actor deactivates for the stated time and then returns to the previous stage
A trained actor activates for the stated time (stage 16) and then deactivates
A trained actor activates for the stated time to the last stage used and then
deactivates
The activation threshold time of a trained actor is programmed
The deactivation threshold time of a trained actor is programmed
A trained actor switches to stage 16 for the stated time, then returns to the previous
stage
A trained actor switches to the last used stage for the stated time, then returns to
the previous stage
If a key is configured with this "command", it has no function
