2
Install the filters
Place the HEPA Filter
1
within the Filter Frame with
the tabs facing up.
Do not install the filter backwards or
the unit will not operate properly.
Place the Active Carbon Filter
2
on top of the HEPA Filter
with the bands (2 places)
facing up.
Place the Pre-filter through
3
the bands (2 places) located
at the corners of the Active
Carbon Filter.
Insert the tabs of the pre-filter into
the associated holes of the Filter
Frame.
Mount the Filter Frame to
4
the main unit.
Fill in the usage start date
5
on the Date Label.
Use the date as a guide for the
Filter Replacement schedule.
Active Carbon Filter
Date Label
E-7
HEPA Filter
Filter Frame
Band
HEPA Filter
Filter Frame
Band
Holes
Main unit
Filter Frame
Band
Tabs
Tabs (4 places)
