2
Mount wall mounting bracket
• Mount the bracket using the included wood screws so that it is maintained level.
Installation on a concrete, block or mortar surface
Drill holes of at least 35 mm depth and 5 mm diameter into the wall, drive in
Fisher plugs, and fix the unit with wood screws.
Installation on a wooden pillar, crosspiece or other wooden surface
Use wood screws for installation.
Caution
• To install the unit on a wooden wall that is less than 10 mm thick, consult your
dealer and have them confirm the strength of the wall before installation.
• Install the unit on a wall, wooden pillar, crosspiece, etc. that is flat and strong
enough.
• Make sure that the unit is installed in an upright position, without leaning to
the right or left.
Wood screw
Installation on a
wooden pillar
Installation on a
wooden crosspiece
Wood screws (4)
35mm
Hole on the wall
Fisher plug
Wooden pillar
Wall mounting bracket
E-7
φ5mm
Wooden crosspiece
