Table of contents
1 Introduction ........................................................
2 Product description (Fig. 1-16)...........................
3 Scope of delivery................................................
4 Proper use..........................................................
5 Safety instructions..............................................
6 Technical data....................................................
7 Unpacking ..........................................................
8 Assembly............................................................
9 Commissioning...................................................
10 Operation ...........................................................
11 Maintenance.......................................................
12 Transport (Fig. 14) .............................................
13 Storage...............................................................
14 Electrical connection ..........................................
15 Repair & ordering spare parts ............................
16 Disposal and recycling .......................................
17 Troubleshooting .................................................
18 EU Declaration of Conformity.............................
19 Exploded view ....................................................
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Wear hearing protection.
If dust builds up, wear respiratory protection!
Wear safety goggles.
Attention! Danger of injury! Do not reach into
saw blade while it is running!
Attention! Laser beam
Protection class II (double insulation).
22 | GB
22
22
1

Introduction

23
23
Manufacturer:
24
Scheppach GmbH
27
Günzburger Straße 69
27
D-89335 Ichenhausen
28
Dear Customer
28
We hope your new product brings you much enjoyment
and success.
29
Note:
31
In accordance with the applicable product liability laws,
32
the manufacturer of this product assumes no liability for
32
damage to the product or caused by the product arising
32
from:
32
• Improper handling
33
• Non-compliance with the operating manual
34
• Repairs carried out by third parties, unauthorised spe-
cialists
34
• Installing and replacing non-original spare parts
50
• Improper use
• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / VDE0113 not being observed.
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2

Product description (Fig. 1-16)

1. On/off switch
2. Locking switch
3. Handle
4. Saw head
5. Moving saw blade guard
5a. Fixing screw
6. Saw blade
7. Locking screw for rotary table
8. Stop rail
8a. Moveable stop rail
8b. Locking screw
9. Fixed saw table
10. Table inlay
11. Scale
12. Pointer
13. Rotary table
14. Locking screw for workpiece support
www.scheppach.com
The product complies with the applicable
European directives.
