1. Use the maintenance tool (f) to unscrew the sight
glass (7) and drain the oil.
2. To prevent the oil from running out uncontrollably,
place a container under the drain plug and use it
to collect the oil.
m ATTENTION: The used oil must be disposed
of at the appropriate waste oil collection point!
3. Fill the new oil (approx. 30 ml) into the oil filling
opening until the oil level has reached the target.
4. Screw the sight glass back on.
5. Check the oil level once more after a short period
17. Repair & ordering spare parts
After repairs or maintenance, make sure that all safe-
ty-related parts are installed and are in perfect con-
dition. All parts which may cause injury must be kept
where they are inaccessible to children or others.
Attention: According to the German Product Liabili-
ty Act, no liability is accepted for damage caused by
improper repairs or by not using original spare parts.
Such work should be performed by a customer service
centre or an authorised specialist. The same applies to
accessory parts.
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the
front page.
Connections and repairs
Connections and repair work on the electrical equip-
ment may only be carried out by electricians.
Important note in the case of repairs:
For return delivery of the product for repair, please en-
sure for safety reasons that it is free of oil and fuel when
it is sent to the service centre.
17.1 Ordering spare parts
Please provide the following information when order-
ing spare parts:
• Model designation
• Item number
• Type plate data
Spare parts / accessories
Flat chisel – Article no.:
Pointed chisel – Article no.:

17.2 Service information

With this product, it is necessary to note that the fol-
lowing parts are subject to natural or usage-related
wear, or that the following parts are required as con-
sumables.
Wearing parts*: chisels, carbon brushes
* = may not be included in the scope of delivery!
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the
front page.

18. Disposal and recycling

Notes for packaging
Notes on the electrical and electronic equipment
act (ElektroG)
• Used batteries or rechargeable batteries that are
not installed permanently in the old device must be
removed non-destructively before disposal! Their
disposal is regulated by the battery act.
• Owners or users of electrical and electronic devices
are legally obliged to return them after use.
• The end user is responsible for deleting their per-
sonal data from the old device being disposed of!
• The symbol of the crossed-out dustbin means that
waste electrical and electronic equipment must not
be disposed of with household waste.
• Waste electrical and electronic equipment can be
handed in free of charge at the following places:
- Public disposal or collection points (e.g. municipal
- Points of sale of electrical appliances (stationary
3908201108
3908201109
www.scheppach.com
The packaging materials are recy-
clable. Please dispose of packag-
ing in an environmentally friendly
manner.
Waste electrical and electronic equipment
does not belong in household waste, but
must be collected and disposed of sepa-
rately!
works yards)
and online), provided that dealers are obliged to
take them back or offer to do so voluntarily.
GB | 27
