GB
This Testboy Car Tester is only to be used within specified voltage range and not domestic mains supply.
Voltage range 6 – 48 Volt/ IP 40.
1.) Only hold the handle, do not touch crocodile clip when testing.
2.) Voltage testing
Attach crocodile clamp to earth (bare metal on the car) (earth is always negative).
Attach test probe of Testboy Car Tester to supply e.g. fuse, battery, test terminal, etc. The LED (+) lights
up when voltage is present.
3.) Battery testing
Crocodile clamp on negative pole of the battery, test probe of Testboy Car Tester on positive pole. The
LED (+) lights up when voltage is present.
4.) Hedlight / rearlight test
Attach crocodile clamp to earth and test probe to lamp socket.
5.) Testing leads
Attach crocodile clamp to earth. Pull back pin by means of push mechanism, clamp the car lead into
wedge and pierce with pin, the LED (+) lights up when voltage is present.
After voltage test minute hole in lead closes again.
6.) Lead test positive / negative
Pierce car lead, attach crocodile clamp to positive or negative pole of battery.
The LED (+) lights up when placed on a negative pole, thus showing that a positive lead is present. The
reverse being the case for a negative lead.
Declaration of conformity
This product is in conformity with standards of low voltage in accordance with the regulations 2006/95/EC,
2004/108/EC.
Fields of application
The tool is intended for use in applications as described in the operating instructions only.
Any other form of usage is not permitted and can lead to accidents or destruction of the device. Any misuse
will result in the expiry of all guarantee and warranty claims on the part of the operator against the
manufacturer.
Instructions for use
