SATA HRS Betriebsanleitung Seite 37

Operating Instructions for SATA HRS
US
Art.
No.
[6­8] 157305
[6­9] 8300
[6­10] 95208
[6­11] 68890 *
[6­12] 15438 ** Paint needle packing
[6­13] 41806
[6­14]
8318 *
[6­15]
8359
[6­16] 11510
[6­17] 17111
[6­18] 11445 *
[6­19] 11544 *
[6­20] 53082 *
[6­21] 10322
[6­22]
208 *
161158
* Available in repair kit 161158 only
16. EU Declaration of Conformity
We hereby declare that the product named in the following, on the basis
of its conception, construction and type of construction in the model we
have brought on the market, corresponds to the fundamental safety re-
quirements of the 94/9/EC guideline, EC Directive 2014/34/EC including
the changes applicable at the time of this declaration and can be used
according to EC-Directive 94/9/EC, EC Directive 2014/34/EC in explosion
hazard areas (ATEX), appendix X, B.
Manufacturer
SATA GmbH & Co. KG
Domertalstraße 20
D-70806 Kornwestheim
Product designation
■ SATA HRS
ATEX Symbol
II 2 G T4
492
Description
Trigger
Suction pipe for HRS-E
Washer
Valve, complete
1 liter aluminum pressure cup
Sealing ring
Quick connect coupling
Mixing cap
Safety valve
Pressure spring for air piston
Compression spring for paint needle
O-ring 0.5" x 0.1", made of Perbunan
Guide bushing
Material flow control nut
HRS repair kit
** Available as service unit
Quan­
tity
1 ea.
1 ea.
1 ea.
1 set
1 set
1 ea.
1 ea.
1 ea.
1 ea.
1 ea.
1 ea.
1 ea.
1 ea.
1 set
1 ea.
1 set
