SATA HRS Betriebsanleitung Seite 36

Art.
No.
[5­8] 157305
[5­9] 8300
[5­10] 68890 *
[5­11] 15438 ** Paint needle packing
[5­12] 41806
[5­13] 226290 * Flat seal
[5­14]
226282
[5­15]
8359
[5­16] 11510
[5­17] 38034
[5­18] 11502
[5­19] 11445 *
[5­20] 11544 *
[5­21]
53082 *
[5­22]
11437 *
[5­23] 10322
161158
* Available in repair kit 161158 only
15.3. HRS­E
Art.
No.
[6­1] 10322
[6­2] 38034
[6­3] 11460 *
[6­4]
11494
[6­5]
133983
[6­6] 3426 *
[6­7] 12591 *
Operating Instructions for SATA HRS
Description
Trigger
HRS suction pipe
Valve, complete
1 liter plastic pressure cup
Pressure tank adapter
Quick connect coupling
Mixing cap
Paint needle for flow control, complete with
needle bush
Paint needle, complete with needle bush
Pressure spring for air piston
Compression spring for paint needle
O-ring 0.5" x 0.1", made of Perbunan
End screw
Guide bushing
HRS repair kit
Description
Guide bushing
Paint needle for flow control, complete with
needle bush
Air piston
Cam rod, complete with O-ring
Air connection piece, 1/4"(male thread)
Safety washer
Bracket bolt
** Available as service unit
US
Quan­
tity
1 ea.
1 ea.
1 set
1 set
1 ea.
1 ea.
1 ea.
1 ea.
1 ea.
1 set
1 set
1 ea.
1 ea.
1 ea.
1 ea.
1 ea.
1 set
Quan­
tity
1 ea.
1 set
1 ea.
1 set
1 ea.
1 ea.
1 ea.
