PROUSER RUBY Montageanleitung Und Sicherheitsvorschriften Seite 56

The bicycle carrier can be cleaned with a mild cleaning agent, with warm water
and/or a soft cloth. First remove any coarse dirt and dust.
Do not use any solvents or similar cleaning agents, since these can
damage the bicycle carrier.
Clean the bicycle carrier regularly when used in coastal areas or in winter
conditions in order to wash off any salt and prolong the service life of the bicycle
carrier.
Store the bicycle carrier in a dry and protected area when not used for extended
periods (e.g. over winter) in order to prolong the service life of the bicycle
carrier.
ADJUSTMENT OF THE QUICK CONNECTOR
Carry out this maintenance operation only if the bicycle carrier cannot be fitted
firmly to the trailer coupling, as described in the chapter "Fitting the bicycle
carrier to the trailer coupling".
Remove the bicycle carrier from the trailer coupling, as described under
"Dismantling the bicycle carrier".
Loosen the locking nut slightly (fig. 2).
•
Screw in the setting screw one quarter of a turn (fig. 2).
•
Tighten the locking nut (fig. 3)
•
Check whether the carrier is now firmly seated on the trailer coupling, as
•
described under "Fitting the bicycle carrier to the trailer coupling". If not,
repeat the above steps.
1
3
2
56
