PROUSER RUBY Montageanleitung Und Sicherheitsvorschriften Seite 44

TECHNICAL DATA
Itemnumber
Tiltable
Material
Own weight
Carrying capacity (max.)
The bicycle carrier is suitable for the transport of two bicycles at most. Please
check the maximum permissible ball load. You can find it on the identification
plate of the tow bar of your car (for most cars this is 75kg). The total weight of
the bicycle carrier with the bicycles cannot exceed the maximum permissible ball
load of the tow bar.
Pro-User Ruby:
Max. permissible ball load Weight bicycle carrier
50kg
60kg
75kg
90kg
+
Pro-User Ruby :
Max. permissible ball load Weight bicycle carrier
50kg
60kg
75kg
90kg
COUPLING REQUIREMENTS
WARNING!
Personal injury is possible due to breakage of the trailer coupling.
The coupling could break if the bicycle carrier is fitted to a coupling made
of a too soft material.
Fit the bicycle carrier only to a coupling made of steel St52, grey cast
•
iron GG52 or higher quality.
Never fit the bicycle carrier to a coupling made of aluminium, other
•
light metals or plastic.
Only suitable for use on the coupling of a passenger car.
•
Fit the bicycle carrier only to trailer couplings with the
following properties:
Material:
D-value:
Tow ball:
Note the instructions of the coupling manufacture.
Pro-User Ruby
91742
No
Steel/plastic
13kg
50kg
13kg
13kg
13kg
13kg
13,5kg
13,5kg
13,5kg
13,5kg
min. steel St52 or grey cast iron GG52
>7,6 kN
Ø50mm (class A-50 according
EC 94/20 or ECE R55)
44
+
Pro-User Ruby
91743
Yes
Steel/plastic
13,5kg
50kg
Max. carrying
capacity
37kg
47kg
Max. 50kg
Max. 50kg
Max. carrying
capacity
36,5kg
46,5kg
Max. 50kg
Max. 50kg
