Use '+' to scroll through the options:
5.4

Showing and changing the speed-step mode

In this section you learn:
what throttle-notches are
-
which throttle-notches are available to you
-
how to select different throttle-notches for individual locomotive
-
addresses.
The area from stopped to maximum speed of a locomotive is divided
into a series of throttle-notches. The more notches present, the
smaller the division between different locomotive speeds. With the
LH100 you can set the displayed locomotive address to have 14, 27,
28 or 128 throttle-notches.
How many speed-step modes are available is depending on the
command station and the software version of the command station.
Address LZ100 /
LZV100 V3
1 - 99 14, 27, 28,
128
100 - 9999 28, 128
1 3 8
LZ100 V2
14, 27, 28
-
Information LH100 V3.6
Functions F0 to F12 are transmitted
cyclically.
Functions F0 to F20 are transmitted
cyclically.
Functions F0 to F28 are transmitted
cyclically.
Functions F0 to F4 are transmitted
cyclically.
Press 'Enter' to confirm your
selection.
LZ100 V1.5 SET02 / 03
14 14, 28, 128
- 14, 28, 128
compact
14, 28, 128
-
