26 Information Set LH101-R
2

Connection and initial operation

The Set LH101-R may be connected to the following components of
®
the Digital plus by Lenz system:
LZ100 or LZV100 from version 3.6; LZV200 from version 3.8.
2.1 Connecting the LTM101 receiver to the central
unit
Connect the XpressNet port of the LTM101 to the XpressNet port of
your control panel or an LA152 adapter.
If you have not already done so, switch on the central unit.
Now the blue LED on the LTM101 is flashing, the LTM101 is waiting
for the connection with the LH101-R.
