Combining Locomotives With Different Speed Step Numbers Into A Double Header; Disassembling A Double Header - Lenz Digital Plus Lh100 Informationsblatt

Information LH100 V3.6
7.3 Combining locomotives with different speed
step numbers into a double header
You can combine locomotives with different speed steps into a double
header. The speed step corresponding to the speed step of the
individual locomotive will always be shown.
Example:
The locomotive with address 24 has 14 speed steps, the locomotive
with address 78 has 28 speed steps. If you now see the maximum
speed step 14 when showing locomotive address 24, then after you
switch over to locomotive address 78 you will see speed step 28,
since that is the maximum speed step for locomotive 78.
7.4

Disassembling a double header

Go through the following steps:
Press On the display you see
The display shows the most
recently chosen menu
You can use the 'Esc' key to interrupt the disassembling of the double
header at any time in this process before you press the final 'Enter'
key.
If the double header is disassembled, the display will again show an
"E" in front of the locomotive address.

You can disassemble a double header even when the speed of
the locomotive in not currently 0!
Explanation
Call up one of the two locomotives
that are assembled into a double
header on your hand held controller.
When you want to dissemble the
double header press the '2' key,
This display flashes. If you want to
disassemble the double header, then
press 'Enter', if not, press 'Esc'.
The double header was
disassembled.
33
