1
Erste Schritte
First Steps
Premier démarrage
SET101
Art. Nr. / art. no. / Art. n° 60101
st
e
1. Auflage / 1
edition / 1
édition, 0319
B.B.10.0064

Werbung

loading

Inhaltszusammenfassung für Lenz Digital plus SET101

  • Seite 1 Erste Schritte First Steps Premier démarrage SET101 Art. Nr. / art. no. / Art. n° 60101 1. Auflage / 1 edition / 1 édition, 0319 B.B.10.0064...
  • Seite 2 Geräte. Wenn Sie Fragen haben, auf die Sie auch nach Durcharbeit dieser Informationen keine Antwort finden, so helfen wir Ihnen gerne weiter. Auf vier verschiedene Arten können Sie mit der Lenz Elektronik GmbH Kontakt aufnehmen: Postanschrift: Lenz Elektronik GmbH...
  • Seite 3 Digital plus by Lenz ® Die Komponenten des SET101 des Systems wurden vor Auslieferung einem intensiven Test unterzogen. Lenz Elektronik GmbH garantiert für einen fehlerfreien Betrieb, wenn Sie die folgenden Hinweise beachten: Die Komponenten des SET101 dürfen nur mit anderen Komponenten Digital plus by Lenz ®...
  • Seite 4 Erste Schritte SET101 Funktionsumfang des SET101 Mit dem SET101 können Sie unter anderem:  bis zu 9999 Digitalloks und  eine konventionelle Lok steuern,  bis zu 29 Funktionen in Lokdecodern schalten,  Funktionen in Lokdecodern auf Dauer- oder Momentbetrieb einstellen, ...
  • Seite 5 Systemaufbau Diese Grafik zeigt einfachen Systemaufbau ® Digital plus by Lenz Systems.
  • Seite 6 Erste Schritte SET101 Anschluss Die Anschlüsse an der LZV200 sind als steckbare Schraubklemmen ausgeführt. 4.1 Anschluss der LZV200 an die Gleise Verbinden Sie die Klemmen J und K der LZV200 mit dem Anschlussgleis Ihrer Modellbahn: Anschluss 2-Leiter-Gleise Anschluss Gleis mit Mittelleiter Gleisanschluss der LZV200 Es dürfen keine Kondensatoren zur Funkentstörung in der Gleisanlage...
  • Seite 7 4.2 Anschluss des Handreglers LH101 an die LZV200 Den 5-poligen DIN-Stecker des Anschlusskabels stecken Sie in die 5- polige DIN-Buchse an der Rückseite Ihrer LZV200: 4.3 Anschluss der LZV200 an den Transformator Verbinden Sie die Klemmen U und V der LZV200 mit den Anschlussklemmen des Transformators TR150.
  • Seite 8 Erste Schritte SET101 Inbetriebnahme Stecken Sie den Netzstecker des Transformators in die Steckdose. Ihre erste Fahrt Wir gehen in diesem Beispiel davon aus, dass Sie eine Lok mit der Adresse 3 (Adresse eines Decoders in Werkseinstellung) einsetzen. 5.1.1 Lokadresse aufrufen: Bei der ersten Inbetriebnahme des LH101 wird die Lokadresse "L0001"...
  • Seite 9 … ggf. bis zum Stillstand. 5.1.3 Fahrtrichtung ändern: Bringen Sie zum Wechseln der Fahrtrichtung die Fahrstufe auf 0" Danach können Sie die Richtung der Lok ändern: Aktion Display Erläuterung Der Druck auf den Drehknopf ändert die Richtung der Lokomotive. Die geänderte Richtung wird im Display angezeigt.
  • Seite 10 Erste Schritte SET101 5.1.5 Lichtfunktion im Lokdecoder schalten: Aktion Display Erläuterung Mit der Taste '0' schalten Sie die Funktion 0 allgemeinen richtungsabhängige Stirnbeleuchtung der Lokomotive) ein und auch wieder aus. Funktion eingeschaltet, so wird dies im Display in der unteren Zeile angezeigt. Nun haben Sie in Kürze erfahren, wie Sie mit dem LH101 eine Lokomotive steuern können.
  • Seite 11 SET101 in the operating manuals of the respective devices. If you still have unanswered questions even after reading this operating manual, then please contact us. There are four different ways of contacting Lenz Elektronik GmbH: Postal Lenz Elektronik GmbH address:...
  • Seite 12 ® The components of the SET101 of the system were submitted to intensive testing before delivery. Lenz Elektronik GmbH guarantees fault-free operation if you follow the advice given below: The components of the SET101 are authorised for operation only with Digital plus by Lenz ®...
  • Seite 13  connect up to 30 other operating devices and much more. You will find more detailed information in the LZV200, LH101 (SET101). System design This graphic presentation shows the simple system design of the ® Digital plus by Lenz system.
  • Seite 14 First Steps SET101 Connection and initial operation All the LZV200 connections are designed as pluggable terminal screws. 4.1 Connecting the LZV200 to the tracks Connect terminals J and K of the LZV200 to the siding track of your model railway: Connection: 2-wire tracks Connection: track with neutral wire...
  • Seite 15 4.2 Connecting the manual control LH101 to the LZV200 Plug the 5-pole DIN-plug of the connecting cable into the 5-pole DIN- plug at the rear of your LZV200: 4.3 Connecting the LZV200 to the transformer Connect terminals U and V of the LZV200 to the connecting terminals of the transformer TR100 (or TR200) Connections U,V to the power supply of the LZV200...
  • Seite 16 First Steps SET101 Initial operation Plug the mains plug of the transformer into the mains plug socket. Operating your first train In this example we assume that you are using a locomotive with the address 3 (ex-factory address of a decoder). 5.1.1 Calling up a locomotive address: During initial operation, locomotive address "L0001"...
  • Seite 17 … down to a standstill. 5.1.3 Changing the direction of travel: To change the direction of travel, first set the speed step to “0”. You can now change the direction of travel Action Display Explanation Press the rotary knob to change the direction of travel of the locomotive.
  • Seite 18 First Steps SET101 5.1.5 Switching the light function of the locomotive decoder: Action Display Explanation Use the '0' key to switch function 0 (usually the direction-dependent head light of the locomotive) on and off. If this function is enabled, this is shown in the bottom line of the display.
  • Seite 19 Si vous désirez poser des questions à propos de sujets sur lesquels ces modes d'emploi ne vous donnent pas de réponse, veuillez nous contacter. Il existe différentes possibilités de contacter la firme Lenz Elektronik GmbH. Adresse...
  • Seite 20 ® Les composants du SET101 du système ont subi un test intensif avant leur mise sur le marché. Lenz Elektronik GmbH garantit un fonctionnement impeccable si vous respectez les règles suivantes. Les composants du SET101 ne peuvent être utilisés qu’avec les Digital plus by Lenz ®...
  • Seite 21 Fonctionnalité du SET101 Avec le SET90 / SET101, vous pouvez :  piloter jusqu'à 9999 locomotives digitales et  une locomotive conventionnelle ;  commuter jusqu'à 28 fonctions dans les décodeurs de locomotive ;  régler dans le décodeur de locomotive les fonctions sur fonctionnement permanent ou momentané...
  • Seite 22 Premier démarrage SET101 Structure du système graphique montre structure simple système Digital plus by Lenz.
  • Seite 23 Connexions et mise en service Les connexions à la LZV200 se font au moyen de bornes à vis. 4.1 Connexion de la LZV200 à la voie Reliez les bornes J et K de la LZV200 à la voie. Connexion à la voie en système 2 rails.
  • Seite 24 Premier démarrage SET101 4.2 Connexion du régulateur LH101 à la LZV200 Insérez l'extrémité munie d’une fiche pentapolaire DIN mâle dans la douille pentapolaire femelle située sur la face arrière de votre LZV200. 4.3 Connexion de la LZV200 au transformateur Reliez les bornes U et V de la LZV200 aux bornes du transformateur TR100 (ou TR200).
  • Seite 25 Mise en service Insérez la fiche du transformateur dans la prise de courant domestique. Votre première conduite Dans cet exemple, nous supposons que vous pilotez une locomotive possédant l’adresse 3 (adresse d’un décodeur encodé en usine). 5.1.1 Appel de l’adresse de locomotive : Lors de la première mise en service du LH101, celui-ci indique l’adresse "L 0001".
  • Seite 26 Premier démarrage SET101 5.1.2 Pilotage de la locomotive: Vous commandez la vitesse et le sens de marche de la locomotive au moyen du curseur rotatif. Action Ecran Explication Tournez le curseur dans le sens horaire pour augmenter la vitesse. Tournez le curseur dans le sens antihoraire pour diminuer la vitesse, …...
  • Seite 27 5.1.4 Arrêt d'urgence : Action Ecran Explication Pressez le curseur rotatif et maintenez la pression jusqu'à ce que "! ETEINT !" soit affiché. Le courant est maintenant coupé sur la voie. Pour rebrancher le courant, pressez à nouveau le milieu du curseur rotatif … …...
  • Seite 28 échappé à la vigilance du traducteur.Sous réserve de modifications, d'erreurs et de possibilités de livraison. Vogelsang 14 35398 Giessen Support: 06403 900 133 Fax: 06403 900 155 www.lenz-elektronik.de support@lenz-elektronik.de Diese Betriebsanleitung bitte für späteren Gebrauch aufbewahren! Keep this operation manual for future reference!
