Motherboard Manual
1.4 R P C
EAR ANEL
PS/2
Keyboard / Mouse
USB2.0X2 VGA
NOTE: HDMI, DVI-D & VGA ports only work with an Intel integrated Graphics Processor.
NOTE: USB3.0 (only supported by Windows 7) ports are backward compatible with
USB2.0/USB1.X devices.
NOTE: Maximum resolution:
HDMI: 1920 x 1200 @60Hz, compliant with HDMI 1.4a
DVI: 1920 x 1200 @60Hz
VGA: 2048 x 1536 @75Hz
NOTE: This motherboard supports Multiple VGA output:
Display Devices
VGA
DVI-D
HDMI
A = Single Pipe Single Display, Intel® Dual Display Clone (Only
24-bpp), or Extended Desktop Mode
C = Clone Mode
E = Extended Desktop Mode
1
S = Single Pipe Single Display With One Display Device
Disabled
X = Unsupported / Note Applicable
4
manuals search engine
ONNECTORS
LAN
HDMI DVI-D USB3.0X2
VGA
DVI-D
X A
A X
1
A S , C, E
Line In/
Surround
Line Out
Mic In 1/
Bass/ Center
HDMI
A
1
S , C, E
