FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee that
interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents
here of and specially disclaims any implied warranties of merchantability or
fitness for any purpose. Further the vendor reserves the right to revise this
publication and to make changes to the contents here of without obligation to
notify any party beforehand.
Duplication of this publication, in part or in whole is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we will not
be responsible for any mistakes found in this user's manual. All the brand and
product names are trademarks of their respective companies.
M
7
V
I
G
-
D
M
7
V
I
G
-
D
M
7
V
I
G
-
D
i

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Biostar M7VIG-D

  • Seite 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Seite 2: Inhaltsverzeichnis

    CPU Installation ......................4 DDR DIMM Modules: DDR1-2 ..................5 Jumpers, Headers, Connectors & Slots ................ 6 ESPAÑOL ....................12 Características del M7VIG-D ..................12 Contenido del Paquete ....................13 Disposición del M7VIG-D....................14 Instalación del CPU ...................... 15 Módulos DDR DIMM: DDR1-2 ..................16 Conectores, Cabezales, Puentes y Ranuras ...............
  • Seite 3: English

    English M7VIG-D Features CPU: Supports the single AMD Socket A for Athlon (Thunderbird )/ Athlon / Duron processors. Running at 200/ 266MHz Front Side Bus. Chipset: North Bridge: VIA VT8375 (KM266) Chipset. South Bridge: VT8235 Chipset. Main Memory Supports up to 2 DDR devices.
  • Seite 4: Package Contents

    BIOS AWARD legal Bios. Supports APM1.2. Supports ACPI. Supports USB Function. Operating System Offers the highest performance for Windows 98, Windows NT, Windows 2000, Windows Me, Windows XP, LINUX and SCO UNIX. Dimensions Micro ATX Form Factor: 22.9cm X 21.3cm (W X L) Package contents HDD Cable X 1, FDD Cable X 1, Fully Setup Driver CD X 1 Flash Memory Writer for BIOS update X 1...
  • Seite 5: Layout Of M7Vig-D

    Layout of M7VIG-D JKBMS1 JATXPWER1 JKBV1 JCFAN1 JUSBV2 JUSB4 JCOM1 JPRNT1 IDE1 IDE2 JGAME1 VT8375 JUSBV1 JVGA1 (KM 266) JUSBLAN1 Winbond BAT1 JAUDIO BIOS JUSB3 PCI1 VT 8235 PCI2 JUSBV3 JPANEL1 JSFAN1 Codec JCODECSEL FDD1 JWOL1 JCMOS1...
  • Seite 6: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU. Press the lever down.
  • Seite 7: Ddr Dimm Modules: Ddr1-2

    DDR DIMM Modules: DDR1-2 DRAM Access Time: 2.5V Unbuffered DDR 200/266MHz (without ECC) Type required. DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin) DIMM Socket DDR Module Total Memory Location Size (MB) DDR 1 64MB/128MB/256MB/512MB/1GB Max is DDR 2 64MB/128MB/256MB/512MB/1GB * The list shown above for DRAM configuration is only for reference.
  • Seite 8: Jumpers, Headers, Connectors & Slots

    Jumpers, Headers, Connectors & Slots Hard Disk Connectors: IDE1/ IDE2 The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA / 33/ 66/ 100/ 133 functionality. It has two HDD connectors IDE1 (primary) and IDE2 (secondary). The IDE connectors can connect a master and a slave drive, so you can connect up to four hard disk drives.
  • Seite 9 Wake On LAN Header: JWOL1 Ground 5V_SB Wake up JWOL1 Clear CMOS Jumper: JCMOS1 JCMOS1 Assignment Normal Operation Pin 1-2 on (default) Clear CMOS Data Pin 2-3 on Front USB Header: JUSB3 Pin Assignment Pin Assignment Data (-) Data (-) Data (+) Data (+) JUSB3...
  • Seite 10 5V/ 5VSB Selection for USB: JUSBV1/2/3 JUSBV1/2/3 Assignment Pin 1-2 on 5V_SB Pin 2-3 on CPU Frequency Selection: JCLK1 Close ==> 100 MHz Open ==> 133 Mhz JCLK1 5V/ 5VSB Selection for Keyboard: JKBV1 JKBV1 Assignment Pin 1-2 on 5V_SB Pin 2-3 on AMR Codec Primary/ Secondary Selection: JCODECSEL Assignment...
  • Seite 11 Case Open Connector: JCI1 JCI1 Assignment Normal Operation No jumper (default) installed Case Open Pin 1-2 on Front Panel Connector: JPANEL1 PWR_LED ON/OFF (+) (-) HLED ==> Speaker Conn. HLED ==> Hard Driver LED ==> Reset Button ==> Infrared Conn. ==>...
  • Seite 12 Audio Subsystem: JF_AUDIO/ JCDIN1 JAUDIO1 JCDIN1 JF_AUDIO JCDIN1 (Front Audio Header) (CD-ROM Audio-In Header) (Front Audio Header) (CD-ROM Audio-In Header) JF_AUDIO Assignment Assignment Mic In Ground Mic Power Audio Power RT Line Out RT Line Out Reserved LFT Line Out LFT Line Out Front Panel Audio Connector/ Jumper Block Jumper Setting...
  • Seite 13 Game Header: JGAME1 JGAME1 Pin Assignment Pin Assignment Ground MIDI-OUTR Ground MIDI-INR Back Panel Connectors JUSBLAN1 JKBMS1 JPRNT1 PS/2 Mouse Line In Parallel JUSB4 Speaker Mic In PS/2 COM1 VGA1 Keyboard JCOM1 JVGA1 JAUDIO...
  • Seite 14: Español

    Español Características del M7VIG-D CPU: Soporta procesadores single AMD Socket A para Athlon (Thunderbird Athlon XP / Duron Corre a 200/ 266MHz Front Side Bus. Chipset: North Bridge: VIA VT8375 (KM266) Chipset. South Bridge: VT8235 Chipset. Memoria Principal Soporta hasta 2 dispositivos DDR.
  • Seite 15: Contenido Del Paquete

    Soporta ACPI. Soporta función USB. Sistemas Operativos Ofrece el más alto funcionamiento para Windows 98, Windows NT, Windows 2000, Windows Me, Windows XP, LINUX y SCO UNIX. Dimensiones Factor de Forma Micro ATX: 22.9cm X 21.3cm (W X L) Contenido del Paquete Cable HDD X 1 Cable FDD X 1 Completa Configuración del Driver CD X 1...
  • Seite 16: Disposición Del M7Vig-D

    Disposición del M7VIG-D JKBMS1 JATXPWER1 JKBV1 JCFAN1 JUSBV2 JUSB4 JCOM1 JPRNT1 IDE1 IDE2 JGAME1 VT8375 JUSBV1 JVGA1 (KM 266) JUSBLAN1 Winbond BAT1 JAUDIO BIOS JUSB3 PCI1 VT 8235 PCI2 JUSBV3 JPANEL1 JSFAN1 Codec JCODECSEL FDD1 JWOL1 JCMOS1...
  • Seite 17: Instalación Del Cpu

    Instalación del CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Seite 18: Módulos Ddr Dimm: Ddr1-2

    Módulos DDR DIMM: DDR1-2 DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/ 266 MHz (sin ECC) Tipo requerido. DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM (184 pin) Localización Total del del Módulo Tamaño de Módulo DDR DIMM Memoria (MB) DDR 1 64MB/128MB/256MB/512MB/1GB Máximo de...
  • Seite 19: Conectores, Cabezales, Puentes Y Ranuras

    Conectores, Cabezales, Puentes y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalidad Ultra DMA 33/ 66/ 100/ 133. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así...
  • Seite 20 Cabezal Wake On LAN: JWOL1 Tierra 5V_SB Wake up JWOL1 Puente de Borrar CMOS: JCMOS1 Asignacion JCMOS1 Operacion Normal Contacto (Default) 1-2 on Borrar Datos Contacto CMOS 2-3 on Cabezal Frontal USB: JUSB3 JUSB3 Contactos Asignacion Contactos Asignacion Data (-) Data (-) Data (+) Data (+)
  • Seite 21 5V/ 5VSB Selección para USB: JUSBV1/2/3 JUSBV1/ 2/ 3 Asignacion Contactos 1-2 on 5V_SB Contactos 2-3 on Selección de Frecuencia del CPU: JCLK1 Cerrado ==> 100 MHz Abierto ==> 133 Mhz JCLK1 5V/ 5VSB Selección para Teclado: JKBV1 JKBV1 Asignacion Contactos 1-2 on 5V_SB...
  • Seite 22 AMR Codec de Selección Primario/ Secundario: JCODECSEL Asignacion JCODECSEL Contacto Codec Primario Onboard (Default) Contacto AMR Codec Primario. Conector Case Open: JCI1 JCI1 Asignacion Operacion Normal Puente sin (default) instalar Carcasa Abierta Contacto 1-2 on Conector del Panel Frontal: JPANEL1 PWR_LED ON/OFF (+) (-)
  • Seite 23 Conector Digital de Audio: JSPDIF1 (Optional) SPDIF_OUT JSPDIF1 Subsistema de Audio: JF_AUDIO1/ JCDIN1 JF_AUDIO1 JCDIN1 (Cabezal de Audio Frontal) (Cabezal de Entrada de Audio CD-ROM) JF_AUDIO Contactos Asignacion Contactos Asignacion Tierra Entrada del MIC Corriente del MIC Corriente de Audio RT Salida de Linea RT Salida de Linea Reservado...
  • Seite 24 Conector del Panel Frontal de Audio/ Jumper Block Jumper Setting Configuracion La senal de salida de linea del Audio Contacto 5 & 6 encamina al conector de la salida de linea Contacto 9 & 10 del Audio ubicado en el panel trasero. La senal de salida de linea del Audio y la senal del entrada del mic estan disponibles No jumpers...
  • Seite 25: Deutsch

    Deutsch Merkmals des M7VIG-D CPU: Unterstützt Athlon™ (Thunderbird™) / Athlon XP™ / Duron ™ Prozessoren für einzeln AMD Sockel A. Mit FSB 200/ 266MHz. Chipsatz: Northbridge: VIA VT8375 (KM266) Chipsatz. Southbridge: VT8235 Chipsatz. Hauptspreicher Unterstützung für 2 DDR Geräte. Unterstützung für 200/266MHz(ohne ECC) DDR Geräte.
  • Seite 26: Verpackungsinhalt

    Unterstützung für ACPI. Unterstützung für USB Function. Betriebsysteme Unterstützung für die am meisten verbreiteten Betriebsysteme wie Window 98, Windows NT, Windows 2000, Windows ME, Windows XP, LINUX and SCO UNIX Abmessungen Micro ATX Form-Factor:: 22.9cm X 21.3cm (W X L) Verpackungsinhalt HDD Kable X 1 FDD Kable X 1...
  • Seite 27: Layout Des M7Vig-D

    Layout des M7VIG-D JKBMS1 JATXPWER1 JKBV1 JCFAN1 JUSBV2 JUSB4 JCOM1 JPRNT1 IDE1 IDE2 JGAME1 VT8375 JUSBV1 JVGA1 (KM 266) JUSBLAN1 Winbond BAT1 JAUDIO BIOS JUSB3 PCI1 VT 8235 PCI2 JUSBV3 JPANEL1 JSFAN1 Codec JCODECSEL FDD1 JWOL1 JCMOS1...
  • Seite 28: Installation Der Cpu

    Installation der CPU Ziehen Sie den Hebel seitwärts von der Sockel und neigen Sie ihn um 90-Grad nach oben. Suchen Sie Pin A im Sockel und den weißen Punkt oder die Abschnittkante in der CPU. Passen Sie Pin A mit dem weißen Punkt/der Abschnittkante zusammen und legen Sie danach die CPU ein.
  • Seite 29: Ddr-Dimm-Modules: Ddr1-2

    DDR-DIMM-Modules: DDR1-2 DRAM Zugriffszeit: 2.5V unbuffered DDR 200/266MHz (ohne ECC) Typen required. DRAM Typen: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM-Module (184-Pin) DIMM-Sockel DDR-Module Speichergröße (MB) Standort DDR 1 64MB/128MB/256MB/512MB/1GB maximal DDR 2 64MB/128MB/256MB/512MB/1GB * Die obere Liste für DRAM-Konfiguration wird als Referenz gezeigt. Installation von DIMM-Modulen 1.
  • Seite 30: Jumpers, Headers, Connectors & Slots

    Jumpers, Headers, Connectors & Slots Festplattenanschlüsse: IDE1 und IDE2 Das Mainboard hat einen 32-Bit Enhanced PCI IDE-Controller, der die Modi PIO0~4, Bus Master sowie die Ultra DMA/33/66/100/133- Funktion zur Verfügung stellt. Dieser ist mit zweii HDD-Anschlüssen versehen IDE1 (primär) und IDE2 (sekundär).
  • Seite 31 Wake On LAN Header: JWOL1 Grund 5V_SB Erwachen JWOL1 Clear CMOS Jumper: JCMOS1 Beschreibung JCMOS1 Normale Operation Pin 1-2 (Default) geschlossen CMOS-Daten Pin 2-3 l schen geschlossen Front USB Header: JUSB3 Pin Beschreibung Pin Beschreibung Data (-) Data (-) Data (+) Data (+) Grund Grund...
  • Seite 32 5V/ 5V_SB Auswahl für USB: JUSBV1/2/3 JUSBV1/2/3 Beschreibung Pin 1-2 geschlossen Pin 2-3 5V_SB geschlossen CPU Frequenz Auswahl: JCLK1 geschlossen ==> 100 MHz geoffnet ==> 133 Mhz JCLK1 5V/ 5VSB Auswahl für Tastatur: JKBV1 JKBV1 Beschreibung Pin 1-2 geschlossen 5V_SB Pin 2-3 geschlossen...
  • Seite 33 Auswahl für Primär/ Sekundär AMR Codec: JCODECSEL Beschreibung J_CODECSEL Pin1-2 Primar Onboard geschlossen Codec(Default) Primar AMRCodec Pin 2-3 geschlossen Anschluss für Gehäuse-Öffnen: JCI1: JCI1 JCI1 Normale Kein Jumper Operation geschlossen (Default) Pin 1-2 Gehause offnen geschlossen Front Panel Connector: JPANEL1 PWR_LED ON/OFF (+) (-)
  • Seite 34 Digital-Audio-Anschluss: JSPDIF1 (optional) SPDIF_OUT Grund JSPDIF1 Audio Subsystem: JF_AUDIO/ JCDIN1 JAUDIO1 JCDIN1 JF_AUDIO JCDIN1 (Front Audio Header) (CD-ROM Audio-In Header) (Front Audio Header) (CD-ROM Audio-In Header) JF_AUDIO1 Beschreibung Beschreibung Mic-In Grund Mic Power Audio Power RT Line-Out RT Line-Out Reserviert LFT Lin-Out LFT Line-Out...
  • Seite 35 Audio-Anschl sse f r die Vorderseite/ Jumper-Block Jumper-Einstellen Konfiguration Audio-Ausgang-Singals werden zu der Audio- Pin 5 und 6 Ausgang-Anschluss an der R ckwand geleitet. Pin 9 und 10 Audio-Ausgang- und Mic-In-Singals sind verf gbar Kein Jumper f r Audio-Anschl sse an der Vorderseite. installieren Game Header: JGAME1 JGAME1...
  • Seite 36: Anschlüsse Auf Der Rückseite

    Anschlüsse auf der Rückseite JUSBLAN1 JKBMS1 JPRNT1 PS/2- Maus Parallel Line-In JUSB4 Lautsprecher- Ausgang Mic-In PS/2- COM1 VGA1 Tastatur JCOM1 JVGA1 JAUDIO...
  • Seite 37: Warpspeeder

    WarpSpeeder Introduction [ WarpSpeeder™ ], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Seite 38: Installation

    Installation Execute the setup execution file, and then the following dialog will pop up. Please click “Next” button and follow the default procedure to install. When you see the following dialog in setup procedure, it means setup is completed. If the “Launch the WarpSpeeder Tray Utility” checkbox is checked, the Tray Icon utility and [WarpSpeeder™] utility will be automatically and immediately launched after you click “Finish”...
  • Seite 39: Usage

    Usage The following figures are just only for reference, the screen printed in this user manual will change according to your motherboard on hand. [WarpSpeeder™] includes 1 tray icon and 5 panels: 1. Tray Icon: Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar.
  • Seite 40 This utility is responsible for conveniently invoking [WarpSpeeder™] Utility. You can use the mouse by clicking the left button in order to invoke [WarpSpeeder™] directly from the little tray icon or you can right-click the little tray icon to pop up a popup menu as following figure.
  • Seite 41 3. Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not. The default setting is “No”.
  • Seite 42 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure.
  • Seite 43 Overclock Panel contains the these features: a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment. Warning: Manually overclock is potentially dangerous, especially when the overclocking percentage is over 110 %. We strongly recommend you verify every speed you overclock by click the Verify button.
  • Seite 44 “Auto-overclock button”: User can click this button and [ WarpSpeeder™ ] will set best stable performance frequency automatically. [ WarpSpeeder™ ] utility will execute a series of testing until system fail. Then system will do fail-safe reboot by using Watchdog function. After reboot, the [ WarpSpeeder™...
  • Seite 45 5. Hardware Monitor Panel Click the Hardware Monitor button in Main Panel, the button will be highlighted and the Hardware Monitor panel will slide out to left as the following figure. In this panel, you can get the real-time status information of your system. The information will be refreshed every 1 second.
  • Seite 46 Note: Because the overclock, overvoltage, and hardware monitor features are controlled by several separate chipset, [ WarpSpeeder™ ] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’ functions.
  • Seite 47: Trouble Shooting

    Trouble Shooting PROBABLE SOLUTION No power to the system at all Power light don’t * Make sure power cable is securely plugged in illuminate, fan inside power supply does not turn * Replace cable on. Indicator light on keyboard does not turn on * Contact technical support PROBABLE SOLUTION...
  • Seite 48: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE SOLUCIÓN No hay corriente en el sistema. La luz de * Asegúrese que el cable de transmisión esté corriente no ilumina, ventilador dentro de la seguramente enchufado. fuente de alimentación apagada. Indicador de * Reemplace el cable. luz del teclado apagado.
  • Seite 49: Problemlösung

    Problemlösung MÖGLICHE URSACHE LÖSUNG Das System hat keine Spannungsversorgung. * Versichern Sie sich, dass das Stromkabel richtig Die Stromanzeige leuchtet nicht, der Lüfter im angebracht ist Inneren Stromversorgung wird nicht * Ersetzen Sie das Stromkabel eingeschaltet. Tastaturleuchten sind nicht an. * Wenden Sie sich an Ihre Kundendienststelle MÖGLICHE URSACHE LÖSUNG...
