F_USB1/F_USB2: Headers for USB 2.0 Ports at Front Panel
These headers allow user to connect additional USB cable on the PC front panel,
and also can be connected with internal USB devices, like USB card reader.
JFRONT_USB3_1: Header for USB 3.0 Ports at Front Panel
This header allows user to connect additional USB cable on the PC front panel,
and also can be connected with internal USB devices, like USB card reader.
Pin
Assignment
1
VBUS0
2
SSRX1-
3
SSRX1+
4
Ground
5
SSTX1-
6
SSTX1+
7
Ground
8
D1-
9
D1+
10
ID
NOTE: USB3.0 is only supported by Windows 7.
manuals search engine
B 7 5 M U 3 +
Assignment
Pin
1
+5V (fused)
2
+5V (fused)
3
USB-
4
USB-
5
USB+
F_USB 1
6
USB+
7
Ground
F_USB 2
8
Ground
2
10
9
Key
10
NC
1
9
1
10
20
11
Pin
Assignment
11
D2+
12
D2-
13
Ground
14
SSTX2+
15
SSTX2-
16
Ground
17
SSRX2+
18
SSRX2-
19
VBUS1
20
Key
15
