FCC Statement and Copyright
This equipment has been tested and found to comply with the limits of a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. There is no guarantee that
interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents
here of and specially disclaims any implied warranties of merchantability or fitness
for any purpose. Further the vendor reserves the right to revise this publication
and to make changes to the contents here of without obligation to notify any party
beforehand.
Duplication of this publication, in part or in whole is not allowed without first
obtaining the vendor's approval in writing.
The content of this user's is subject to be changed without notice and we will not
be responsible for any mistakes found in this user's manual. All the brand and
product names are trademarks of their respective companies.
i

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für Biostar m7ncd Pro

  • Seite 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Seite 2: Inhaltsverzeichnis

    ENGLISH..................... 1 M7NCD Pro Features...................... 1 Package contents ......................2 Layout of M7NCD Pro..................... 3 CPU Installation ......................4 DDR DIMM Modules: DIMMB1/ DIMMB2/ DIMMA1 ............5 Jumpers, Headers, Connectors & Slots ................ 6 DEUTSCH ....................12 M7NCD Pro Merkmale ....................12 Verpackungsinhalt......................
  • Seite 3: English

    English M7NCD Pro Features ® Supports the AMD Socket 462 processor up to XP 3000+. Running at 200/266/333/400 MHz Front Side Bus. Chipset North Bridge: nForce2 SPP. South Bridge: MCP. High Speed 800Mb/s Hyper-Transport interface to the MCP. Main Memory Supports up to 3 DDR devices.
  • Seite 4: Package Contents

    Supports USB Function. Operating System Offers the highest performance for MS-DOS, Windows 98SE, Windows 2000, Windows Me, Windows XP, SCO UNIX etc. Dimensions ATX Form Factor: 24.4cm X 30.5cm (W X L) Package contents HDD Cable X 1 FDD Cable X 1 Fully Setup Driver CD X 1 User’s Manual X 1 USB Cable X 2 (Optional)
  • Seite 5: Layout Of M7Ncd Pro

    Layout of M7NCD Pro...
  • Seite 6: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU. Press the lever down.
  • Seite 7: Ddr Dimm Modules: Dimmb1/ Dimmb2/ Dimma1

    DDR DIMM Modules: DIMMB1/ DIMMB2/ DIMMA1 For Dual-channel DDR (128-bit) high performance, at least 2 or more DIMM modules must be installed. (It has to be the combination of DIMMA and DIMMB.) With only one DIMM installed, the memory performs only at 64-bit. DRAM Access Time: 2.5V Unbuffered DDR 200/266/333/400 MHz Type required.
  • Seite 8: Jumpers, Headers, Connectors & Slots

    Jumpers, Headers, Connectors & Slots Hard Disk Connectors: IDE1/ IDE2 The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA / 33/ 66/ 100/ 133 functionality. It has two HDD connectors IDE1 (primary) and IDE2 (secondary). The IDE connectors can connect a master and a slave drive, so you can connect up to four hard disk drives.
  • Seite 9 Wake On LAN Header: JWOL1 Wake up Ground 5V_SB JWOL1 Front USB Header: JUSB1/ JUSB2 Pin Assignment Pin Assignment Data (-) Data (-) Data (+) Data (+) JUSB1/2 Ground Ground 5V/ 5V_SB Selection for KB: JKBV1 JKBV1 Assignment Pin 1-2 on Pin 2-3 on 5V_SB...
  • Seite 10 5V/ 5V_SB Selection for USB: JUSBV1/JUSBV2/JUSBV4 JUSBV1/ 2/ 4 Assignment Pin 1-2 on 5V_SB Pin 2-3 on Front Panel Connector: JPANEL1 PWR_LED ON/OFF (+) (-) HLED ==> Speaker Conn. HLED ==> Hard Driver LED ==> Reset Button ==> Infrared Conn. ==>...
  • Seite 11 JF_AUDIO1 Assignment Assignment Mic In Ground Mic Power Audio Power RT Line Out RT Line Out Reserved LFT Line Out LFT Line Out *JF_AUDIO1 only support 2CH. Front Panel Audio Connector/ Jumper Block Jumper Setting Configuration Pin 5 and 6 Audio line out signals are routed Pin 9 and 10 to the back panel audio line out connector.
  • Seite 12 Remove AC JCMOS wait 15 JCMOS power line Pin2-3 close seconds Pin1-2 close AC power Reset the password as you wish or clear CMOS data Case Open Connector: JC1 Case Open Signal Ground Back Panel Connectors JKBMS1 JUSBLAN1 JPRNT1 JGAME1 PS/2 LAN(Optional) Mouse...
  • Seite 13 LED indicator for Lan port status: Status Normal Download Speed Right light: green 10Mbps Light: blink Left light: no Right light: green 100Mbps Light: blink Left light: orange...
  • Seite 14: Deutsch

    Deutsch M7NCD Pro Merkmale Unterstützung für AMD Prozessor(Sockel 462) bis zu XP 3000+. FSB 200/266/333/400MHz.. Chipsatz Northbridge: nForce2 SPP. Southbridge: MCP. 800Mb/s Hohe Geschwindigkeit : Hyper-Transport -Interface zu den MCP Chipsatz. Hauptspeicher Unterstützung für 3 DDR Geräte. Unterstützung für 200/266/333/400MHz(ohne ECC) DDR Geräte.
  • Seite 15: Verpackungsinhalt

    Unterstützung für AWARD legal Bios. Unterstützung für APM1.2. Unterstützung für ACPI. Unterstützung für USB Function. Betriebsystem Unterstützung für die am meisten verbreiteten Betriebsysteme wie Windows 98SE, Windows 2000, Windows ME, Windows XP und SCO UNIX usw. Abmessungen ATX Form-Factor: 24.4cm X 30.5cm (W X L) Verpackungsinhalt HDD Kable X 1 FDD Kable X 1...
  • Seite 16: Layout Von M7Ncd Pro

    Layout von M7NCD Pro...
  • Seite 17: Installation Der Cpu

    Installation der CPU Ziehen Sie den Hebel seitwärts von der Sockel und neigen Sie ihn um 90-Grad nach oben. Suchen Sie Pin A im Sockel und den weißen Punkt oder die Abschnittkante in der CPU. Passen Sie Pin A mit dem weißen Punkt/der Abschnittkante zusammen und legen Sie danach die CPU ein.
  • Seite 18: Ddr-Dimm-Modules: Dimmb1/Dimmb2/ Dimma1

    DDR-DIMM-Modules: DIMMB1/DIMMB2/ DIMMA1 Für Dual-Kanal DDR(128-bit) High-Performance mußt mindenstens zwei oder mehr DIMM-Modules installieren. (Der Speicher mußt in der Kombination von DIMMA und DIMMB installiert werden.) Wenn man nur ein Dimm installiert, funktioniert die Speicher nur 64-bit. DRAM Zugriffszeit: 2.5V unbuffered DDR 200/266/333/400 MHz Typen erfordert. DRAM Typen: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM-Module (184 pin) DIMM-Sockel DDR-Module...
  • Seite 19: Jumper, Header, Anschlüsse & Slots

    Jumper, Header, Anschlüsse & Slots Festplattenanschlüsse: IDE1 und IDE2 Das Mainboard hat einen 32-Bit Enhanced PCI IDE-Controller, der die Modi PIO0~4, Bus Master sowie die Ultra DMA/33/66/100/133- Funktion zur Verfügung stellt. Dieser ist mit zweii HDD-Anschlüssen versehen IDE1 (primär) und IDE2 (sekundär).
  • Seite 20: Auswahl Von 5V/ 5Vsb Für Kb: Jkbv1

    Wake On LAN Header: JWOL1 Wake-Up Masse 5V_SB JWOL1 Front USB Header: JUSB1/ JUSB2 Pin Beschreibung Pin Beschreibung Data (-) Data (-) Data (+) Data (+) JUSB1/2 Masse Masse Kein Schl ssel ü Auswahl von 5V/ 5VSB für KB: JKBV1 JKBV1 Beschreibung Pin 1-2...
  • Seite 21 Anschlüsse auf der Vorderseite: JPANEL1 PWR_LED EIN/AUS (+) (-) HLED ==> Lautsprecheranschl. HLED ==> Festplattenanzeige ==> Reset-Taste ==> Infrarotanschl. ==> Sleep-Taste PWR_LED ==> Stromanzeige EIN/ AUS ==> Ein-/ Ausschalttaste Audio Subsystem: JF_AUDIO1/ JCDIN1 JAUDIO1 (Cabezal de Audio Frontal) JCDIN1 (Cabezal de Entrada de Audio CD-ROM) JF_AUDIO1 Beschreibung Beschreibung...
  • Seite 22 Audio-Anschl ü sse für die Vorderseite/ Jumper-Block Konfiguration Jumper-Einstellen Audio-Out-Singals werden zu Pin 5 und 6 der Audio-Out-Anschluss an Pin 9 und 10 der R ckwand geleitet. ü Audio-Out- und Mic-In-Singals sind Kein Jumper verf ügbar ür Audio-Anschlüsse an der installiert Vorderseite Clear CMOS Jumper: JCMOS...
  • Seite 23: Anschlüsse Auf Der Rückseite

    Case Open Connector: JC1 öffnen Geh äuse Signal Ground Masse Anschlüsse auf der Rückseite JUSBLAN1 JKBMS1 JPRNT1 LAN(optional) PS/2- JGAME1_USB1 Maus Parallel Game-Port Mic- In Line-In PS/2- COM1 COM1 COM2 Tastatur JCOM1 JCOM2...
  • Seite 24: Watchdog Technology

    Watchdog Technology It is important to know that when overclocking, the system can be at a vulnerable state. Therefore, the BIOSTAR Watchdog Technology was designed to protect your PC under dangerous over-clock situations. Any over-clocking that reaches the threshold settings, the Watchdog Technology will disable your system from rebooting in the BIOS setting.
  • Seite 25: Trouble Shooting

    Trouble Shooting PROBABLE SOLUTION No power to the system at all Power light don’t * Make sure power cable is securely plugged in illuminate, fan inside power supply does not turn * Replace cable on. Indicator light on keyboard does not turn on * Contact technical support PROBABLE SOLUTION...
  • Seite 26: Problemlösung

    Problemlösung MÖGLICHE URSACHE LÖSUNG Das System hat keine Spannungsversorgung. Die * Versichern Sie sich, dass das Stromkabel richtig Stromanzeige leuchtet nicht, der Lüfter im Inneren angebracht ist der Stromversorgung wird nicht eingeschaltet. * Ersetzen Sie das Stromkabel Tastaturleuchten sind nicht an. * Wenden Sie sich an Ihre Kundendienststelle MÖGLICHE URSACHE LÖSUNG...
  • Seite 27 04/8/2003...
