5 IN 1 WORKBENCH

Peg Fence

Positioning Seat of
Aluminum
6
Insert the two positioning seats of aluminum block
into the groove of the corresponding aluminum
block.
Line up the positioning seat of aluminum block with
the corresponding hole on the worktable plate to
be inserted. Move aluminum block downwards to
insert into the worktable plate.
The aluminum block has grooves on both
sides which can be used to install the choosen
positioning seat of aluminum block.
© DUKE & VALE
English
Aluminum Block
Positioning Seat of
Aluminum
Aluminum Block
Worktable Plate
